Nokia 3HE00027CA 3HE00027CAAA01 SFP GIGE SX LC, ROHS 6/6, DDM, -40/85C, FTLF8519P3BTL-A6 IPUIBDKDAA

This Nokia 3HE00027CA 3HE00027CAAA01 optics is a high performance and cost-effective small form factor pluggable transceiver. It is suitable for 1000BASE-SX Gigabit Ethernet and 1G Fibre Channel application. The product is programmed and tested to work with Alcatel-Lucent Nokia Gigabit Ethernet Switches, Ethernet Routers, Network Interface Cards (NICs) and Media Converters.

Specifications

• Brand: Nokia
• Part Numbers: 3HE00027CA, 3HE00027CAAA01, FTLF8519P3BTL-A6, IPUIBDKDAA
• Form Factor: SFP
• Data Rate: 1.25Gb/s
• Wavelength: 850 nm
• Fiber Type: MMF
• Max Distance: 550 m
• Optical Components: VCSEL/PIN
• Transmitter Power: -9 ~ -3 dBm
• Extinction ratio: > 9 dB
• Receiver Sensitivity: < -18 dBm
• Receiver Overload: > 0 dBm
• Connector: LC Duplex
• Digital Diagnostic Monitoring: Yes
• Environment
• Operating: 0°C to 70°C
• Storage: -40°C to 85°C
• Weight: 0.025 kg
