Molex 74576-0005 TDP (Triad Differential Pair) PCIe x1 Cable Assembly, 26 AWG, 5.0m (16.405') Length

745760005 - Molex 74576-0005

Our Price: $315.00

Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days

Product Code: 745760005

Qty:

Description

General

Category: Cable Assemblies
Series: 74576
Part Number: 74576-0005, 0745760005
Assembly Configuration: Dual Ended Connectors
Connector to Connector: PCI Express-to-PCI Express, TDP-to-TDP
Overview: PCI Express Industry Standard Products
Product Name: PCI, PCI Express, TDP
UPC: 822350565738

Physical

Cable Length: 5.0m
Circuits (Loaded): 18
Color - Resin: Natural
Gender: Male-Male
Lock to Mating Part: Yes
Material - Metal: Phosphor Bronze
Material - Plating Mating: Gold
Material - Plating Termination: Tin
Material - Resin: Low Density Polyethylene
Net Weight: 288.200/g
Packaging Type: Bag
Pitch - Mating Interface: 0.64mm
Plating min - Mating: 1.905µm
Plating min - Termination: 2.540µm
Single Ended: No
Termination Interface: Style: Through Hole
Wire Insulation Diameter: N/A
Wire Size AWG: 26
Wire/Cable Type: Round

Electrical

Current - Maximum per Contact: 1.5A
Impedance: 100?
Shielded: Yes
Voltage - Maximum: 40V
