Molex 74576-0006 TDP (Triad Differential Pair) PCIe x1 Cable Assembly, 26 AWG, 6.0m (19.685') Length
745760006 - Molex 74576-0006

Our Price: $380.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: 745760006
Qty:

Description

General
  • Category: Cable Assemblies
  • Series: 74576
  • Part Number: 74576-0006, 0745760006
  • Assembly Configuration: Dual Ended Connectors
  • Connector to Connector: PCI Express-to-PCI Express, TDP-to-TDP
  • Overview: PCI Express Industry Standard Products
  • Product Name: PCI, PCI Express, TDP
  • UPC: 822350565745

Physical
  • Cable Length: 6.0m
  • Circuits (Loaded): 18
  • Color - Resin: Natural
  • Gender: Male-Male
  • Lock to Mating Part: Yes
  • Material - Metal: Phosphor Bronze
  • Material - Plating Mating: Gold
  • Material - Plating Termination: Tin
  • Material - Resin: Low Density Polyethylene
  • Packaging Type: Tray
  • Pitch - Mating Interface: 0.64mm
  • Plating min - Mating: 1.905µm
  • Plating min - Termination: 2.540µm
  • Single Ended: No
  • Termination Interface: Style: Through Hole
  • Wire Insulation Diameter: N/A
  • Wire Size AWG: 26
  • Wire/Cable Type: Round

Electrical
  • Current - Maximum per Contact: 1.5A
  • Impedance: 100?
  • Shielded: Yes
  • Voltage - Maximum: 40V
