PCIe 5.0 Gen-Z 4C+ EDSFF Male to Female Height Increase Test Protection Adapter

The PCIe 5.0 Gen-Z 4C+ EDSFF Male to Female Height Increase Test Protection Adapter is a specialized testing and validation tool designed for engineering development and quality assurance in next-generation computing systems. This adapter provides a controlled height extension between Gen-Z 4C+ EDSFF interfaces while maintaining full PCIe 5.0 signal integrity and power delivery specifications. The adapter incorporates protective features that safeguard expensive host systems and components during testing procedures, making it an essential tool for R&D laboratories, manufacturing facilities, and quality control departments working with Gen-Z and EDSFF technologies.

Features

• Gen-Z 4C+ EDSFF Interface: Full support for Gen-Z 4C+ EDSFF male to female connectivity
• Controlled Height Increase: Precisely engineered extension for testing and measurement access
• Test Protection Circuitry: Integrated protection against shorts, overcurrent, and signal integrity issues
• PCIe 5.0 Performance: Maintains full x16 lane bandwidth at 32 GT/s data rates
• Enhanced Power Delivery: 4C+ configuration supports advanced power management with monitoring
• Signal Integrity Monitoring: Test points for signal quality verification and debugging
• Robust Construction: Industrial-grade materials for repeated testing cycles

Specifications

• Product Model: PCIe 5.0 Gen-Z 4C+ EDSFF Male to Female Height Increase Test Protection Adapter
• Host Interface: Gen-Z 4C+ EDSFF Male
• Target Interface: Gen-Z 4C+ EDSFF Female
• Height Increase: 25mm standard extension (custom options available)
• Data Transfer Rate: Up to 32 GT/s per lane (approximately 512 Gbps total bandwidth)
• Supported Protocols: Gen-Z, PCI Express 5.0
• Protection Features: Overcurrent protection, short circuit protection, signal integrity monitoring
• Test Points: Multiple accessible test points for signal analysis
• Operating Temperature: 0°C to +70°C
• Power Delivery: 12V main power (up to 80W) + 3.3V Vaux power with monitoring
• Construction: Military-grade PCB with reinforced connectors

Applications

• Engineering Validation: Signal integrity testing and validation of Gen-Z systems
• Manufacturing Testing: Production line testing of EDSFF compatible devices
• Quality Assurance: Quality control procedures for Gen-Z and EDSFF products
• R&D Laboratories: Research and development of next-generation interface technologies
• System Integration Testing: Verification of system compatibility and performance
• Signal Analysis: Detailed signal quality measurement and analysis
• Prototype Development: Support for prototype and pre-production system development
• Compliance Testing: Standards compliance verification for Gen-Z and PCIe 5.0 implementations
