USB 9-pin to USB 2.0 Type-A Female Right Side Exit Adapter

The USB 9-pin to USB 2.0 Type-A Female Right Side Exit Adapter is a compact connectivity solution designed for space-optimized system configurations. This adapter converts a standard 9-pin USB motherboard header into a single USB 2.0 Type-A female port with a convenient right-side exit orientation. The right-angle design facilitates improved cable routing and port placement in compact computer cases, small form factor systems, and embedded applications where traditional straight connectors would cause mechanical interference. This solution provides additional USB connectivity while maintaining full USB 2.0 performance and ensuring clean internal cable management in systems with specific spatial constraints.

Features

• Single USB 2.0 Port: One Type-A female port from a standard 9-pin header
• Right Side Exit Design: 90-degree right-angle orientation for optimal cable routing
• Space-Optimized Configuration: Ideal for compact systems and tight installation spaces
• Plug-and-Play Operation: No drivers required for standard USB 2.0 functionality
• Standard USB Header: Compatible with common 9-pin motherboard USB connectors
• Durable Construction: Quality materials ensure reliable long-term performance
• Universal Compatibility: Works with all USB 2.0 devices and peripherals

Specifications

• Product Model: USB 9-pin to USB 2.0 Type-A Female Right Side Exit Adapter
• Host Interface: 9-pin USB Header (Standard motherboard connector)
• Target Interface: USB 2.0 Type-A Female
• Port Orientation: Right-side exit (90-degree right angle)
• Data Transfer Rate: Up to 480 Mbps (USB 2.0 High-Speed)
• Supported Protocols: USB 2.0
• Power Delivery: Standard USB 2.0 power (500mA maximum)
• Operating Temperature: 0°C to +70°C
• Cable Length: 10cm standard
• Connector Type: 9-pin USB header to Type-A female port
• Pin Configuration: Standard USB 2.0 pinout

Applications

• Small Form Factor PCs: Space-optimized USB connectivity in compact computer cases
• Motherboard Port Expansion: Adding an additional USB port to systems with available headers
• Embedded Systems: Industrial and commercial applications requiring compact USB connectivity
• Custom PC Builds: Unique system configurations with specific right-side cable routing requirements
• Kiosk and Digital Signage: Commercial systems needing additional USB ports in limited space
• Test and Development: Prototyping and validation requiring specific port orientation
• Office Workstations: Expanding USB connectivity for peripherals in space-constrained setups
• OEM Solutions: Integration into custom computing products and system assemblies
