Broadcom® BCM957412A4120AC Ethernet Network Interface Card, 10G Dual-Port SFP+, PCIe 3.0 x 8
Broadcom® BCM957412A4120AC Ethernet Network Interface Card, 10G Dual-Port SFP+, PCIe 3.0 x 8

Alternative Views:
Our Price: $245.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Days


Product Code: BCM957412A4120AC
Qty:

Description

Broadcom® BCM957412A4120AC Ethernet Network Interface Card, 10G Dual-Port SFP+, PCIe 3.0 x 8, Tall&Short Bracket.

Overview

The Broadcom® BCM957412A4120AC is a dual-port 10 Gb/s, PCI-Express Gen3 x8 Network Interface Card that supports both SFP+ optical modules and copper direct-attach cable. The card uses the Broadcom BCM57412 10GbE MAC controller with the integrated dual-channel 10GbE SFI transceiver.

Features

  • Dual-port pluggable media interface, which may be equipped with a 10G SFP+ optical transceiver or with copper direct-attach cable.
  • Fully compliant with SFF-8402 standard.
  • x8 PCI Express v3.0 compliant.
  • SR-IOV with up to 128 VFs.
  • Function Level Reset (FLR) support.
  • TruFlow™ flow processing engine.
  • Virtual Network Termination–VXLAN, NVGRE, GRE encap/decap.
  • vSwitch acceleration.
  • Tunnel-aware stateless offloads.
  • RDMA over converged Ethernet (RoCE).
  • SMBus 2.0.
  • MCTP over SMBus.
  • PCIe-based UART and KCS.
  • Jumbo frames up to 9 KB.
  • Advanced Congestion Avoidance.
  • Multiqueue, NetQueue, and VMQ.
  • IPv4 and IPv6 offloads.
  • TCP, UDP, and IP checksum offloads.
  • Large Send Offload (LSO).
  • Large Receive Offload (LRO).
  • TCP Segmentation Offload (TSO).
  • Receive-side Scaling (RSS).
  • Transmit-side Scaling (TSS).
  • VLAN insertion/removal.
  • Interrupt coalescing.
  • Network boot-PXE, UEFI.
  • iSCSI boot.
  • MSI and MSI-X.
  • Supports Wake-on-LAN
  • Conforms to the PCI Express Card Electromechanical Specification Rev. 3.0.

Applications

Dual-Port 10-Gigabit Ethernet Network Interface Card for Data Centers or Cloud Computing.
Specifications

Ports Dual

ASIC BCM57412

Data Rate Per Port 10/1GbE

System Interface Type PCIe 3.0 x 8

Connector Type SFP+

Bracket Height Full Height and Low Profile

RoCE Yes

SR-IOV Yes

TSO Yes

NVGRE Yes

VXLAN Yes

DPDK Yes

NPAR Yes

NVMe-oF Yes

Geneve Yes

OS Support Microsoft Windows, Red Hat Enterprise Linux, and so on

Operating Temperature 0 to 55 °C (32 to 131 °F)

Storage Temperature -40 to 70 °C (-40 to 158 °F)


Broadcom BCM57412 Maximizes Network Performance

Seamless Compatibility With Mainstream Servers

Supporting All Major OS Distributions
