Key Specifications

• Ports: 48 x 10/100/1000Base-T (Gigabit Ethernet) + 4 x 10G SFP+
• Switching Bandwidth: 176 Gb/s
• Forwarding Rate: 130.94 Mpps
• Switching Type: Managed Layer 3 Switch
• Stackable: Yes
• Power Supply: Internal
• Power Consumption: Up to 40W (Max)

Performance & Management

• Performance: Features queuing, jumbo frames (9000 bytes), and support for dynamic routing.
• Management: Accessible via a local web interface, Cisco Business mobile app, and the Cisco Business Dashboard.
• CPU: Dual-core processor up to 1.4 GHz.
• Memory: 1 GB DDR4 RAM, 512 MB Flash memory.

Security Features

• DHCP Snooping
• DoS Attack Prevention
• IP-MAC Port Binding
• IPv6 First Hop Security
• RADIUS Authentication
• Storm Control

Physical & General Information

• Dimensions: 17.5 x 11.3 x 1.7 inches (approx. 445 x 288 x 44 mm).
• Rack Mountable: Yes, fits in a 1U rack unit.
• Certifications: CE, CSA, FCC, UL.
• Cooling: Features a fan for cooling.

Compatible Transceivers

The Cisco C1300-48T-4X switch uses four 10G SFP+ ports for its uplink, and you can use 10G SFP+ transceivers.
