The Cisco Meraki C9300-48T-M is a 48-port Gigabit Ethernet Layer-3 switch with a 256 Gbps switching capacity and 480 Gbps of stacking bandwidth, supporting up to eight switches in a stack. Key features include modular 40G or 10G uplink options, StackPower management, and a 1U rack-mount design. It is managed via the Cisco Meraki cloud platform and includes integrated fans, dual power supply slots for redundancy, and a USB port for additional storage or features.
Cisco Meraki Catalyst 9300-48T — Specifications (Card)
Cisco Meraki Catalyst 9300-48T — Specifications
Primary Information
- Product Description
- Cisco Meraki Catalyst 9300-48T - switch - 48 ports - managed - rack-mountable
- Device Type
- Switch - 48 ports - L3 - managed - stackable
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 48 x 10/100/1000
- Performance
- Switching capacity: 256 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48 Mpps
- Capacity
- QoS queues: 8 ¦ Member ports per aggregated link: up to 8 ¦ VLANs with trunking: 4094
- MAC Address Table Size
- 32000 entries
- Routing Protocol
- MSTP, RSTP, STP, IGMP, static IP routing, OSPFv2, VRRP
- Remote Management Protocol
- SNMP, Syslog, DHCP, IPv4, IPv6
- Features
- Cisco StackPower technology, adaptive policy, ZTP, usage statistics, firmware upgradable, network diagnostics, push notification, QoS, DSCP to CoS Mutation, VLAN support, VLAN trunking, PVST, RPVST, STP BPDU Guard, STP loop guard, STP Root Guard, UDLD, Broadcast Storm Control, CDP, port mirroring, PIM, DHCP server, DHCP relay, RBAC, MAB, sticky MAC, DHCP snooping, DAI, ACL support, hot swappable 3 fans
- Compliant Standards
- IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.1x
- Power
- AC 100-240 V (50 - 60 Hz)
- Power Redundancy
- Optional
- Dimensions (W×D×H)
- 17.5 in × 17.7 in × 1.7 in
- Weight
- 16.42 lbs
- Manufacturer Warranty
- Limited lifetime warranty
General
- Device Type
- Switch - 48 ports - L3 - managed - stackable
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 48 x 10/100/1000
- Performance
- Switching capacity: 256 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48 Mpps
- Capacity
- QoS queues: 8 ¦ Member ports per aggregated link: up to 8 ¦ VLANs with trunking: 4094
- MAC Address Table Size
- 32000 entries
- Max Units in a Stack
- 8
- Routing Protocol
- MSTP, RSTP, STP, IGMP, static IP routing, OSPFv2, VRRP
- Remote Management Protocol
- SNMP, Syslog, DHCP, IPv4, IPv6
- Authentication Method
- RADIUS
- Features
- Cisco StackPower technology, adaptive policy, ZTP, usage statistics, firmware upgradable, network diagnostics, push notification, QoS, DSCP to CoS Mutation, VLAN support, VLAN trunking, PVST, RPVST, STP BPDU Guard, STP loop guard, STP Root Guard, UDLD, Broadcast Storm Control, CDP, port mirroring, PIM, DHCP server, DHCP relay, RBAC, MAB, sticky MAC, DHCP snooping, DAI, ACL support, hot swappable 3 fans
- Compliant Standards
- IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.1x
- Built‑in Devices
- 3 x fans
- Status Indicators
- Status
Expansion / Connectivity
- Interfaces
- 48 x 1000Base-T RJ-45 ¦ 2 x network stack device ¦ 1 x management ¦ 1 x USB Type A ¦ 1 x USB Type B console
- Expansion Slots
- 1 (total) / 1 (free) x expansion slot
Power
- Power Device
- Internal power supply - hot-plug
- Installed Qty
- 1
- Max Supported Qty
- 2
- Power Redundancy
- Optional
- Power Provided
- 350 Watt
- Voltage Required
- AC 100-240 V (50 - 60 Hz)
- 80 PLUS Certification
- 80 PLUS Platinum
Miscellaneous
- Rack Mounting Kit
- Included
- MTBF
- 305,870 hours
- Compliant Standards
- AN/NZS 60950.1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, EN 55032, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR 47 Part 15 Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-2/2015.04, V-3/2015.04, VCCI-CISPR 32 Class A
Dimensions & Weight
- Width
- 17.5 in
- Depth
- 17.7 in
- Height
- 1.7 in
- Weight
- 16.42 lbs
Manufacturer Warranty
- Service & Support
- Limited warranty - advanced replacement - lifetime - response time: next business day
Environmental Parameters
- Min Operating Temperature
- 23 °F
- Max Operating Temperature
- 113 °F
- Humidity Range Operating
- 5 - 90%
- Min Storage Temperature
- -4 °F
- Max Storage Temperature
- 158 °F
|
|
|
 |
|
 |
|
