Two SATA 22P (7+15) Female to Two SATA 7P with One Big 4P Power Cable

The Two SATA 22P (7+15) Female Right Angle to Two SATA 7P Right Angle with One Big 4P Power Cable is a specialized interface conversion and power distribution solution designed to connect two standard SATA devices to host systems while providing centralized power delivery through a single 4-pin peripheral connector. This cable features two right-angle SATA 22-pin (7+15) female connectors on one end, two right-angle SATA 7-pin data connectors on the other end, and an integrated Big 4-pin female power connector. Engineered for reliability and performance in space-constrained environments, this cable enables simultaneous connectivity for two SATA devices while ensuring stable power delivery from a single power source, making it ideal for high-density multi-drive environments, compact server configurations, and storage applications where efficient cable management and space optimization are critical requirements.

Features

• Right-Angle Design: Space-saving right-angle connectors enable efficient cable routing in tight spaces
• Dual Interface Conversion: Converts two right-angle SATA 22-pin (7+15) female interfaces to two right-angle SATA 7-pin data interfaces
• Centralized Power Delivery: Integrated Big 4-pin female power connector provides stable power supply for both connected devices
• High-Speed Performance: Supports SATA 3.0 specifications with up to 6 Gbps data transfer rates per interface
• Enhanced Compatibility: Enables connection of multiple SATA devices to compatible host systems
• Secure Connection: Precision-engineered connectors ensure reliable mating and stable operation
• Efficient Power Management: Single power connector simplifies cable management for multiple drives
• Durable Construction: Quality materials ensure long-term reliability and repeated use

Specifications

• Host Connectors: 2x SATA 22-pin (7+15) Female Right Angle
• Data Connectors: 2x SATA 7-pin Male Right Angle
• Power Connector: Big 4-pin Female (Molex)
• Data Rate Support: Up to 6 Gbps (SATA 3.0 compatible)
• Supported Protocols: SATA 3.0/2.0/1.0
• Power Delivery: Supports standard peripheral power specifications (12V/5V)
• Cable Length: Typically 0.3m, 0.5m (standard options)
• Operating Temperature: -20°C to +85°C
• Durability Rating: 2,500+ mating cycles (SATA connectors)
• Wire Gauge: 28-30 AWG (data), 18-20 AWG (power)
• Shielding: Individual pair shielding with overall braid protection
• Contact Plating: Gold-plated contacts (data connectors)
• Impedance: 100? ±10% (characteristic impedance)

Applications

• High-Density Storage Arrays: Connecting multiple SATA drives in space-constrained storage configurations
• Compact Server Integration: Enabling use of multiple SATA drives in dense server systems with centralized power management
• Data Center Infrastructure: Facilitating multi-drive storage configurations in high-density enterprise environments
• Test Benches: Temporary connectivity for testing and diagnostics of multiple SATA devices in limited-space setups
• Data Recovery: Facilitating simultaneous drive connections for data retrieval operations in compact workstations
• Backup Solutions: Creating flexible backup systems utilizing multiple SATA drives with optimized space utilization
• Technical Support: Field service applications requiring multiple drive connectivity in space-limited scenarios
• Educational Labs: Teaching storage technology and multi-drive management concepts in compact learning environments
