4 Straight SATA 7Pin to 4 Left Bend SATA 7Pin Cable

The 4 Straight SATA 7Pin to 4 Left Bend SATA 7Pin Cable is a specialized multi-lane connectivity solution designed for enterprise storage systems with unique spatial constraints and asymmetric layout requirements. This cable features four independent SATA channels with straight connectors on one end and left-bend connectors on the opposite end, providing an innovative solution for configurations where traditional cable orientations cannot address specific clearance challenges. The left-bend design enables optimal cable routing in systems where connectors must avoid obstructions on the left side while maintaining parallel high-speed data transmission across all channels. Engineered for superior signal integrity and reliable performance, this solution is ideal for non-standard server architectures, custom storage arrays, and specialized computing environments requiring asymmetric connectivity options.

Features

• Asymmetric Connector Design: Straight connectors on one end and left-bend connectors on the opposite end
• Multi-Lane Configuration: Four independent SATA channels in a single cable assembly
• High-Speed Data Transfer: Supports data rates up to 6 Gbps per channel (SATA 3.0)
• Left-Side Clearance Optimization: Left-bend connectors address specific spatial constraints in asymmetric layouts
• Enhanced Signal Integrity: Precision engineering with optimized impedance matching and crosstalk reduction
• Secure Connection: Gold-plated contacts and positive latching mechanisms ensure reliable mating
• Backward Compatibility: Fully compatible with SATA 2.0 and SATA 1.0 devices
• Organized Cable Management: Single cable design reduces clutter while addressing unique routing requirements

Specifications

• Product Model: 4x SATA Straight to Left-Bend Multi-Lane Cable
• Host Connectors: 4x SATA 7-pin, Male, Straight
• Device Connectors: 4x SATA 7-pin, Male, Left Bend (45-degree orientation)
• Data Rate Support: Up to 6 Gbps per channel (SATA 3.0)
• Supported Protocols: SATA 3.0, 2.0, 1.0
• Cable Type: Internal Grade, Round Cable with Individual Channel Separation
• Wire Gauge: 30 AWG per channel
• Impedance: 100? ±10% per channel
• Shielding: Individual channel shielding with overall braid protection
• Cable Length:  0.5m, 1.0m
• Operating Temperature: 0°C to +70°C
• Durability Rating: 5,000 mating cycles per connector
• Minimum Bend Radius: 30mm

Applications

• Asymmetric Server Designs: Ideal for non-standard server architectures with left-side spatial constraints
• Custom Storage Arrays: Perfect for storage systems requiring left-oriented cable routing solutions
• High-Density Racks: Space-optimized configurations in data center environments
• OEM Applications: Designed for system integrators dealing with unique form factor requirements
• Industrial Computing: Suitable for industrial PCs with asymmetric internal layouts
• Test and Development: Laboratory environments requiring specialized cable orientation solutions
• Retrofit Projects: Enables compatibility with legacy systems having left-side clearance limitations
• Specialized Workstations: Professional workstations with unconventional internal configurations
