4 Straight SATA 7Pin to 4 Right Angle SATA 7Pin Cable

The 4 Straight SATA 7Pin to 4 Right Angle SATA 7Pin Cable is a high-density multi-lane connectivity solution designed for enterprise storage systems and space-constrained environments requiring optimized cable management. This cable provides four independent SATA channels within a single assembly, featuring straight connectors on one end and right-angle connectors on the other end. The hybrid design enables efficient cable routing in tight spaces while maintaining excellent signal integrity across all channels. Engineered to support high-speed data transmission, this multi-lane solution ensures reliable parallel connectivity between storage controllers and multiple drives, making it ideal for high-density server configurations, storage arrays, and compact systems where space optimization and organized cable management are critical.

Features

• Multi-Lane Configuration: Four independent SATA channels in a single cable assembly
• Hybrid Connector Design: Straight connectors on one end and right-angle connectors on the opposite end
• High-Speed Data Transfer: Supports data rates up to 6 Gbps per channel (SATA 3.0)
• Space Optimization: Right-angle connectors reduce cable strain and save space in compact systems
• Enhanced Signal Integrity: Precision engineering with optimized impedance matching and reduced crosstalk
• Secure Connection: Gold-plated contacts and latching mechanisms ensure reliable mating
• Backward Compatibility: Fully compatible with SATA 2.0 and SATA 1.0 devices
• Organized Cable Management: Single cable design reduces clutter and improves airflow

Specifications

• Product Model: 4x SATA Straight to Right-Angle Multi-Lane Cable
• Host Connectors: 4x SATA 7-pin, Male, Straight
• Device Connectors: 4x SATA 7-pin, Male, Right Angle
• Data Rate Support: Up to 6 Gbps per channel (SATA 3.0)
• Supported Protocols: SATA 3.0, 2.0, 1.0
• Cable Type: Internal Grade, Round Cable with Individual Channel Separation
• Wire Gauge: 30 AWG per channel
• Impedance: 100? ±10% per channel
• Shielding: Individual channel shielding with overall braid protection
• Cable Length:  0.5m, 1.0m
• Operating Temperature: 0°C to +70°C
• Durability Rating: 5,000 mating cycles per connector
• Minimum Bend Radius: 30mm

Applications

• High-Density Servers: Ideal for rack servers and blade systems with limited clearance
• Storage Arrays: Connecting multiple drives in RAID configurations with space constraints
• Compact NAS Systems: Network-attached storage devices requiring optimized cable routing
• Data Center Infrastructure: Enterprise storage solutions with space-limited configurations
• Workstation Builds: High-performance computing systems with multiple storage devices
• OEM Applications: Designed for system integrators needing space-optimized multi-lane solutions
• Test and Development: Laboratory environments requiring multiple SATA connections with space constraints
• Embedded Systems: Compact computing applications requiring efficient cable management
