OCulink SFF-8611 4i to U.2 SFF-8639 with 15P Power Cable

The OCuLink SFF-8611 4i to U.2 SFF-8639 with 15P Power Cable is a high-performance hybrid solution designed for enterprise storage systems and data centers. This cable converts a single OCuLink SFF-8611 4i host interface to a U.2 SFF-8639 interface while integrating a separate SATA power connector, enabling simultaneous data transmission and power delivery to NVMe SSDs. It provides reliable high-speed connectivity between PCIe-based hosts and U.2 storage devices, making it ideal for storage expansion, server upgrades, and high-density deployments where both data and power need to be delivered efficiently.

Features

• Hybrid Design: Combines data transmission (OCuLink to U.2) and power delivery (15-pin SATA power) in a single cable solution
• High-Speed Performance: Supports PCIe 4.0 data rates up to 16 GT/s per lane (64 GT/s total bandwidth) and U.2 NVMe protocols
• Integrated Power Delivery: Includes 15-pin SATA power connector to eliminate separate power cables for connected U.2 devices
• Enhanced Signal Integrity: Precision engineering with optimized impedance matching and shielding for minimal signal loss
• Reliable Connection: Secure mating with straight connectors ensures stable operation in vibration-prone environments
• Space-Efficient Design: Compact connectors facilitate high-density server configurations
• Dual Protocol Support: Compatible with NVMe PCIe and SATA protocols for flexible storage options
• Robust Construction: High-quality materials ensure durability and long-term reliability in 24/7 operation

Specifications

• Product Model: OCuLink to U.2 with Power Cable
• Host Connector: OCuLink SFF-8611 4i, Male, Straight
• Device Connector: U.2 SFF-8639, 68-Position, Male, Straight
• Power Connector: SATA 15-pin Power
• Data Rate Support: Up to 16 GT/s (PCIe 4.0), NVMe protocols
• Supported Protocols: PCIe 4.0/3.0, NVMe 1.4/1.3, SATA 3.2
• Power Rating: 12V/5V per SATA power connector (conforms to SATA power specifications)
• Wire Gauge: 30 AWG (data), 22 AWG (power)
• Impedance: 85? ±10% (OCuLink), 100? ±10% (U.2)
• Shielding: Individual pair shielding with overall braid protection (data lines)
• Cable Length: 0.5m, 1.0m
• Operating Temperature: -20°C to +85°C
• Durability Rating: 5,000 mating cycles (data connectors), 1,500 cycles (power connector)
• Minimum Bend Radius: 30mm

Applications

• Data Center Storage Expansion: Connecting PCIe host adapters to U.2 NVMe SSDs in storage servers and JBODs
• Server Upgrade Projects: Enabling integration of new servers with OCuLink ports to existing U.2 storage infrastructure
• High-Performance Computing: Ideal for HPC environments requiring high-speed NVMe storage connectivity with integrated power
• Enterprise Storage Arrays: Providing efficient connectivity for large-scale NVMe storage deployments
• OEM Server Manufacturing: Suitable for system integrators building storage-optimized servers with U.2 NVMe drives
• Test and Development Labs: Useful for validating U.2 NVMe configurations and performance benchmarking
• Cloud Infrastructure: Supporting high-density storage solutions in hyperscale computing environments
• AI and Machine Learning Platforms: Providing reliable connectivity for training and inference storage systems
