SlimSAS SFF-8654 4i to 4 Right Angle SATA 7P Cable

The SlimSAS SFF-8654 4i to 4 Right Angle SATA 7P Cable is a high-performance internal breakout cable designed for modern data center and enterprise storage environments where space optimization is critical. This cable provides an efficient interface conversion, splitting a single SlimSAS (SFF-8654) 4-lane host interface into four independent SATA 7-pin connectors with right-angle orientation. Engineered to support high-speed data transfer protocols, this solution enables reliable connectivity from modern host systems to multiple SATA drives while addressing spatial constraints in dense server configurations through its space-saving right-angle connector design.

Features

• Right-Angle Connector Design: Features four right-angle SATA connectors specifically engineered for space-constrained installations, enabling efficient cable routing and minimizing obstruction in high-density server environments
• Modern Interface Integration: Bridges the SlimSAS SFF-8654 4i host interface with multiple SATA 7-pin connectors, providing compatibility between current host systems and legacy SATA drive infrastructures
• High-Speed Data Support: Supports high-speed data transfer protocols including SAS and PCIe, delivering reliable performance for enterprise storage applications with excellent signal integrity
• Optimized Space Utilization: The right-angle connector design significantly reduces the required clearance space, making it ideal for ultra-thin server configurations and high-density storage setups
• Enhanced Signal Integrity: Utilizes precision-engineered cables with multi-layer shielding to minimize signal degradation, crosstalk, and electromagnetic interference
• Secure Connection System: Incorporates robust connectors with positive latching mechanisms to ensure stable connections in vibration-prone environments
• Thermal Management: The low-profile design contributes to improved airflow management in densely packed server configurations

Specifications

• Product Model: SlimSAS SFF-8654 4i to 4 Right Angle SATA 7P Cable
• Connector A: SlimSAS (SFF-8654) 4i, 38-Position, Male, Straight
• Connector B: 4x SATA, 7-Position, Male, Right Angle
• Connector Gender: Male to Male
• Cable Type: Breakout with Right Angle Configuration
• Cable Length: 0.5m,1.0m standard options
• Data Rate Support: Up to 24 Gbps (SAS-4), 16 GT/s (PCIe 4.0)
• Supported Protocols: SAS 3.0/4.0, SATA III 6.0 Gbps, PCI Express 4.0
• Wire Gauge: 30-32 AWG
• Impedance: 85 ? differential impedance
• Shielding: Individual pair shielding with overall braid and foil shield
• Operating Temperature: -40°C to +85°C
• Insertion Loss: Complies with SAS-4 specifications
• Return Loss: Meets SAS-4 requirements
• Durability: Minimum 250 mating cycles
• Maximum Data Transfer Rate: 6.0 Gbps per SATA port

Applications

• High-Density Server Configurations: Ideal for 1U and 2U server environments where right-angle connectors are essential for component clearance and space optimization
• Data Center Storage Expansion: Connecting host bus adapters with SlimSAS interfaces to multiple SATA drives in storage arrays where space constraints require right-angle connector solutions
• Enterprise Storage Systems: Deploying in enterprise storage environments where modern host systems need to connect to legacy SATA drive infrastructures with space-efficient cabling
• Server Manufacturing: Used by server OEMs for configurations requiring right-angle connectors to maximize component density and optimize internal layout
• System Integration Projects: Facilitating storage system integrations where right-angle connectors provide optimal cable routing and avoid interference with other components
• Data Backup Solutions: Supporting backup storage systems and archival solutions that utilize SATA drives while maintaining compact form factors
• Cloud Infrastructure: Deploying in cloud data centers where high-density server configurations require space-optimized connectivity solutions
