M.2 M-key SFF-8643 Contact to Right Angle Internal HD Mini SAS SFF-8643 4i Cable

The M.2 M-key SFF-8643 Contact to Right Angle Internal HD Mini SAS SFF-8643 4i Cable is a specialized adapter solution designed to bridge M.2 M-key interfaces with right-angle HD Mini SAS SFF-8643 internal connectors. This cable enables efficient integration between M.2-based host systems and SAS/SATA storage devices in space-constrained environments. Its right-angle design optimizes cable routing and minimizes obstruction in high-density server configurations while maintaining high-speed data transmission and reliable performance for data center applications.

Features

• High-Speed Performance: Supports SAS-3 12Gb/s and PCIe 4.0 16GT/s data rates, ensuring optimal bandwidth utilization;
• Right-Angle Connector Design: Space-saving right-angle HD Mini SAS connector facilitates clean cable management in tight spaces;
• Dual Protocol Compatibility: Works with both SAS/SATA and PCIe NVMe protocols, offering configuration flexibility;
• Superior Signal Integrity: Precision engineering with 100? impedance matching and individual pair shielding minimizes signal degradation;
• Secure Connection: Robust connectors with positive latching mechanisms ensure vibration-resistant operation;
• Hot-Plug Capable: Supports hot-swapping for maintenance and upgrades without system downtime;
• Durable Construction: High-quality materials ensure reliability through 5,000 mating cycles.

Specifications

• Product Model: M.2 M-key to Right Angle HD Mini SAS Cable;
• Host Connector: M.2 M-key with SFF-8643 contacts;
• Device Connector: Right Angle Internal HD Mini SAS SFF-8643 4i Male;
• Data Rate Support: Up to 12Gb/s (SAS-3), 16GT/s (PCIe 4.0);
• Supported Protocols: SAS-3/2/1, SATA 3.2, PCIe NVMe 1.4/1.3;
• Impedance: 100? ±10%;
• Shielding: Individual pair shielding with overall braided protection;
• Cable Length: 0.5m, 1.0m (standard options);
• Operating Temperature: -20°C to +85°C;
• Durability Rating: 5,000 mating cycles;
• Minimum Bend Radius: 30mm;
• Voltage Rating: 30V per contact.

Applications

• High-Density Servers: Ideal for 1U/2U server configurations where space optimization is critical;
• Storage Expansion: Connecting M.2-enabled systems to SAS/SATA backplanes or drive arrays;
• Data Center Infrastructure: Deploying in space-constrained rack environments requiring right-angle connections;
• OEM System Integration: Building customized storage solutions with M.2 to SAS connectivity;
• Test and Development Labs: Prototyping and validating storage configurations with space constraints;
• Hardware Upgrades: Modernizing systems with M.2 interfaces while maintaining SAS storage compatibility;
• Cloud Computing: Supporting hyperscale storage deployments requiring efficient cable management;
• NVMe to SAS Adaptations: Enabling PCIe NVMe hosts to communicate with SAS-based storage devices.
