MCIO 4x 38P to 4 Right Bend SATA 7P Cable

The MCIO 4x 38P to 4 Right Bend SATA 7P Cable is a specialized high-density breakout solution designed for modern server and storage environments where space optimization and cable management are critical requirements. This advanced cable assembly converts a single MCIO (SFF-TA-1016) 4-lane host interface into four independent SATA 7-pin data ports, featuring strategically engineered right-angle connectors that enable superior cable routing and space utilization in constrained server configurations. Engineered for enterprise storage deployments, this solution provides efficient connectivity for multiple SATA SSDs or HDDs while effectively addressing airflow management challenges in high-density server environments.

Features

• Space Optimized Right Angle Design: 90-degree right-bend SATA connectors facilitate clean cable routing and minimize obstruction in tight storage configurations
• High Density Breakout Architecture: Converts one MCIO 4x host port into four individual SATA data ports, maximizing connectivity in space-constrained environments
• SATA 3.0 Performance: Supports 6.0 Gbps data transfer rates per port, ensuring full compatibility with modern SATA SSDs and high-performance HDDs
• Enhanced Airflow Management: Low-profile right-angle design significantly reduces cable obstruction, improving chassis airflow and thermal performance
• Superior Signal Integrity: Precision engineering with proper impedance matching and shielding maintains signal quality across all four SATA channels while minimizing crosstalk

Specifications

• Product Model: MCIO to Quad SATA Right Bend Cable
• Host Connector: MCIO (SFF-TA-1016) 4x, 38-Position, Male, Straight
• Device Connectors: 4x SATA 7-pin Data, Male, Right Angle (90 degrees)
• Data Rate Support: Up to 6.0 Gbps (SATA 3.0) per port
• Supported Protocols: SATA 3.0, SATA 2.0, SATA 1.0
• Cable Type: Breakout Fanout Configuration
• Wire Gauge: 30 AWG for signal transmission
• Shielding: Individual channel shielding with overall protective layer
• Cable Length: 0.5m, 0.8m, 1.0m standard options
• Operating Temperature: -20°C to +85°C
• Bend Radius: Minimum 30mm recommended
• Durability Rating: Minimum 5,000 mating cycles for SATA connectors

Applications

• High Density Server Storage: Ideal for 1U/2U rack servers where right-angle connectors provide crucial clearance for drive trays and optimal airflow management
• Storage Array Backplanes: Perfect for connecting MCIO host interfaces to SATA backplanes in JBOD and storage array configurations where cable routing space is limited
• Data Center Deployment: Essential for data center environments requiring maximum storage density with optimized thermal management and cable organization
• Cloud Storage Infrastructure: Supports large-scale storage deployments in cloud infrastructure where right-angle connectors enable better serviceability and maintenance
• Enterprise NAS Systems: Suitable for Network Attached Storage systems requiring multiple SATA drive connections with minimal cable obstruction and improved airflow characteristics
