MCIO 4x 38P to SlimSAS SFF-8654 4x 38P Cable, Straight to Straight

The MCIO 4x 38P to SlimSAS SFF-8654 4x 38P Cable is a high-performance internal server cable designed for next-generation data center and enterprise storage applications. This cable provides a critical bridge between the modern, high-density MCIO (Mini Cool Edge IO) host interface (compliant with SFF-TA-1016) and the SlimSAS (SFF-8654) interface found on storage backplanes and devices. It is engineered to deliver exceptional signal integrity, supporting high-speed data transfer protocols like PCIe and SAS, making it ideal for flexible and demanding computing environments.

Features

• Modern Interface Bridge: Provides a reliable and direct connection from the compact, high-density SFF-TA-1016 (MCIO) interface to the SFF-8654 (SlimSAS) interface. This is perfect for PCIe 4.0, PCIe 5.0, and SAS-4 (24 Gbps) applications.
• High-Speed Data Support: Designed to support high data rates, capable of handling the demands of PCIe Gen 4/535 and SAS-418 protocols for both NVMe storage and SAS/SATA drive arrays.
• Superior Signal Integrity: Constructed with precision-engineered cables (commonly 30 AWG) and effective shielding to minimize insertion loss, crosstalk, and electromagnetic interference (EMI), ensuring stable performance at high data rates.
• Space-Efficient and Durable: The SlimSAS connector boasts a compact design that occupies the same area as a Mini-SAS HD 4x connector, aiding in high-density layouts. The MCIO connector often features a secure latching mechanism, and both ends are built for durability.
• Optimized for Internal Use: The flexible cable jacket and form factor facilitate neat routing within server chassis, contributing to improved airflow for thermal management.

Specifications

• Product Model: MCIO 4x to SlimSAS 4x Cable
• Connector A: MCIO (SFF-TA-1016) 4x, 38-Position, Male, Straight
• Connector B: SlimSAS (SFF-8654) 4x, 38-Position, Male, Straight
• Connector Gender: Male to Male
• Cable Type: Straight to Straight
• Cable Length: Common options include 0.5m, 0.8m, 1.0m (Specific lengths may vary by manufacturer)
• Data Rate Support: Up to 16 GT/s (PCIe 4.0), 32 GT/s (PCIe 5.0), 24 Gbps (SAS-4)
• Supported Protocols: PCI Express (PCIe) 4.0/5.03, SAS 3.0/4.0 (SAS-4 24Gbps)
• Typical Wire Gauge: 30 AWG
• Shielding: Individual pair shielding with overall braid + foil shield (common for high-speed cables)
• Operating Temperature: -40°C to +85°C (typical for such connectors)

Applications

• Server Storage Expansion: Connecting a motherboard or Host Bus Adapter (HBA) with an MCIO port to a SAS/SATA or NVMe backplane (using SlimSAS) in rack servers and storage arrays.
• Data Center Infrastructure: Deploying in hyperscale data centers and cloud infrastructure for high-density storage server configurations that utilize both MCIO and SlimSAS interfaces.
• NVMe Flash Arrays and Storage Systems: Enabling high-speed connectivity within all-flash storage arrays, NVMe JBOF (Just a Bunch of Flash) systems, and other enterprise storage solutions that leverage PCIe and SAS protocols.
• High-Performance Computing (HPC): Used in HPC clusters and workstations that require flexible and reliable internal cabling for maximum storage bandwidth and compatibility between different interface standards.
• System Integration and Upgrades: Facilitating system builds, expansions, or upgrades where an adapter cable between the newer MCIO and the established SlimSAS HD interfaces is required.
