SATA 7Pin to SATA 7Pin Cable, Straight to Right Bend

The SATA 7Pin to SATA 7Pin Cable, Straight to Right Bend is a specialized internal connectivity solution designed for modern computing and storage systems requiring optimized cable management in space-constrained environments. This cable features a standard straight connector on one end and a right-bend connector on the other, providing an efficient solution for specific chassis layouts where traditional straight or standard right-angle connectors cannot provide adequate clearance. The right-bend design enables superior cable routing in configurations where connectors must avoid adjacent components or chassis obstructions on the right side. Engineered to support high-speed data transmission, this cable ensures reliable connectivity between SATA controllers and storage devices while addressing specific spatial challenges in advanced system designs.

Features

• Asymmetrical Connector Design: Straight to right-bend configuration for specialized installation scenarios
• High-Speed Data Transfer: Supports data rates up to 6 Gbps (SATA 3.0)
• Space-Specific Optimization: Right-bend connector addresses unique clearance requirements in right-side constrained layouts
• Enhanced Signal Integrity: Precision engineering with optimized impedance matching (100? ±10%)
• Secure Connection: Gold-plated contacts and positive latching mechanism ensure reliable mating
• EMI Protection: Comprehensive shielding minimizes electromagnetic interference
• Backward Compatibility: Fully compatible with SATA 2.0 and SATA 1.0 devices
• Durable Construction: Reinforced strain relief and high-quality materials ensure long-term reliability

Specifications

• Product Model: SATA Straight to Right-Bend Cable
• Connector A: SATA 7-pin, Male, Straight
• Connector B: SATA 7-pin, Male, Right Bend (45-degree orientation)
• Data Rate Support: Up to 6 Gbps (SATA 3.0)
• Supported Protocols: SATA 3.0, 2.0, 1.0
• Cable Type: Internal Grade, Flat Cable
• Wire Gauge: 30 AWG
• Impedance: 100? ±10%
• Shielding: Aluminum foil shielding for EMI protection
• Cable Length: 0.3m, 0.5m, 1.0m
• Operating Temperature: 0°C to +70°C
• Durability Rating: 5,000 mating cycles
• Minimum Bend Radius: 25mm

Applications

• Right-Side Constrained Chassis: Ideal for computer cases with right-side clearance limitations
• Custom Server Racks: Suitable for server configurations requiring right-bend cable orientation
• High-Density Storage Systems: Perfect for storage arrays where right-bend connectors provide optimal component clearance
• Specialized Workstations: Designed for professional workstations with right-side spatial constraints
• OEM and Custom Builds: Essential for system integrators dealing with right-oriented form factor requirements
• Test and Development Labs: Useful for prototyping systems with specific right-side cable routing needs
• Industrial Control Systems: Suitable for industrial PCs with right-side space limitations
• Retrofit and Upgrade Projects: Enables compatibility with systems requiring right-bend connectivity solutions
