SATA 22P (7+15) Male to SATA 22P (7+15) Male Cable

The SATA 22P (7+15) Male to SATA 22P (7+15) Male Cable is a specialized high-speed data and power integration cable designed for modern storage systems and enterprise applications. This cable features a unique 22-pin connector design that combines both the 7-pin SATA data interface and the 15-pin SATA power interface into a single compact connector on both ends. Engineered to support SATA 3.0 specifications, this integrated cable solution provides simultaneous data transmission and power delivery through a single cable assembly, making it ideal for space-constrained environments where cable management and efficient connectivity are crucial.

Features

• Integrated Design: Combines both 7-pin SATA data connector and 15-pin SATA power connector into a single 22-pin interface on both ends, reducing cable clutter and simplifying connections in storage systems.
• High-Speed Data Transfer: Supports SATA 3.0 specifications with data transfer rates up to 6Gbps, ensuring efficient performance for modern storage devices including SSDs and high-speed HDDs.
• Simultaneous Power Delivery: Provides power delivery through the integrated 15-pin power section, eliminating the need for separate power cables and connectors.
• Space Optimization: The compact 22-pin connector design saves valuable space in high-density storage configurations and server environments.
• Secure Connection: Features locking mechanisms and robust connector design to ensure stable connections in vibration-prone environments.
• Backward Compatibility: Maintains compatibility with previous SATA generations (1.5Gbps and 3Gbps) while supporting the latest SATA 3.0 standard.

Specifications

• Product Model: SATA 22P (7+15) Male to SATA 22P (7+15) Male Cable
• Connector A: SATA 22-Pin Male (7-pin data + 15-pin power)
• Connector B: SATA 22-Pin Male (7-pin data + 15-pin power)
• Connector Gender: Male to Male
• Cable Type: Integrated Data and Power Cable
• Cable Length: Standard options: 0.1m. 0.3m, 0.5m
• Data Rate Support: Up to 6Gbps (SATA 3.0)
• Power Rating: +3.3V, +5V, +12V (standard SATA power specifications)
• Supported Protocols: SATA 1.0, 2.0, 3.0
• Wire Gauge: 28AWG (data), 18AWG (power)
• Shielding: Foil shielding for data pairs, overall braid shielding
• Operating Temperature: 0°C to +70°C
• Voltage Rating: 40V DC
• Current Rating: 1.5A per power pin
• Durability: 5000 insertion cycles minimum

Applications

• Enterprise Storage Systems: Ideal for high-density storage arrays and server configurations where space optimization and cable management are critical requirements.
• SSD Arrays: Perfect for connecting multiple solid-state drives in all-flash storage systems that require both high-speed data transfer and power through a single cable interface.
• Server Backplanes: Suitable for use in server backplane designs that utilize integrated SATA connectors for improved reliability and reduced connection points.
• High-Performance Computing: Essential for HPC environments where efficient cable management and reliable connections are necessary for optimal system performance.
• Data Center Deployments: Excellent for data center applications requiring clean cable management and reduced cable clutter in rack-mounted storage systems.
• Embedded Systems: Ideal for space-constrained embedded applications where the combined data and power interface saves valuable space and simplifies system design.
• Storage Expansion Units: Perfect for storage expansion enclosures and JBOD systems that benefit from the integrated connection approach.
