The DGS-1210-52MP is a 52-port Gigabit Smart Managed PoE+ Switch featuring 48 PoE-enabled ports (with mixed 802.3af/at support) and 4 Gigabit/SFP combo ports for uplinks, delivering a 370W total PoE budget, L2+ static routing, and advanced security features like ACLs and D-Link's Safeguard Engine, all in a rack-mountable design with smart fan cooling.

Key Specifications:

• Ports:
• 48 x 10/100/1000BASE-T (PoE/PoE+)
• 4 x Gigabit Ethernet/SFP Combo ports
• Power Over Ethernet (PoE):
• Supports IEEE 802.3af and 802.3at (PoE+)
• Total PoE Budget: 370 Watts
• Time-based PoE and Surveillance Mode for IP cameras
• Switching Performance:
• Switching Capacity: 104 Gbps
• Forwarding Rate: 77.4 Mpps
• Management:
• Web-based GUI with Standard and Surveillance Modes
• Simplified CLI via Telnet, SNMP v1/v2c/v3
• L2+ Static Routing
• Security Features:
• D-Link Safeguard Engine to protect CPU
• Access Control Lists (ACLs)
• 802.1X, Guest VLAN, IP-MAC-Port Binding (IMPB)
• ARP Spoofing Prevention, DHCP Server Screening
• Network Features:
• VLANs (up to 256 static)
• Link Aggregation (802.3ad)
• Spanning Tree Protocols (STP, RSTP, MSTP)
• Loopback Detection, Cable Diagnostics
• Physical & Environmental:
• Rack-mountable (1U height)
• Smart fan for temperature-based cooling
• Operating Temperature: -5 to 50 °C
• Power: Internal Universal Power Supply (100-240 VAC)

Compatible Transceivers

The DGS-1210-52MP is compatible with SFP transceivers for fiber optic connections.
