The DGS-3130-54S is a 54-port, lite Layer 3 stackable managed switch with 48 SFP Gigabit ports, 2 x 10GbE copper ports, and 4 x 10G SFP+ uplink ports. Key specs include a 216 Gbps switching capacity, 161 Mpps forwarding rate, support for stacking up to 6 units, and advanced security and routing features.

Ports and interfaces

• Gigabit Access: 48 x SFP ports
• 10GbE Uplinks: 2 x 10GBASE-T ports
• 10G SFP+ Uplinks: 4 x 10G SFP+ ports
• Console: 1 x 10/100/1000BASE-T RJ-45 for out-of-band management
• Management: 1 x 10/100/1000BASE-T RJ-45 for out-of-band IP management
• USB: 1 x USB 2.0 Type A port

Performance and capacity

• Switching Capacity: 216 Gbps
• Packet Forwarding Rate: 161 Mpps
• Packet Buffer: 4 MB
• VLANs: 4000 virtual interfaces
• Stacking: Up to 6 units per stack

Management and security

• Routing: Lite Layer 3 with support for static routing and dynamic protocols like RIP
• Security: Access Control Lists (ACLs), 802.1X, IP-MAC-Port Binding, DHCP Snooping, and more
• Encryption: SSL, SSL 2.0, and SSL 3.0
• Authentication: Secure Shell v.2 (SSH2)

Physical and Environmental

• Dimensions: 440mm×290mm×44mm (17.32in×11.42in×1.73in)
• Weight: 3.72 Kg
• Power Consumption: 131 W (max)
• Fans: 4 Smart Fans
• Power Supply: Internal, with optional redundant power supply support

Compatible Transceivers

The D-Link DGS-3130-54S switch is compatible with a range of D-Link branded SFP (1 Gbps) and SFP+ (10 Gbps) transceivers.
