100 Gigabit Dual Port QSFP28 Intel E810-CAM2-BASED Low Latency Ethernet Network Interface Card
100 Gigabit Dual Port QSFP28 Intel E810-CAM2-BASED Low Latency Ethernet Network Interface Card



Alternative Views:
Our Price: $689.00
Warranty: 1 Year Warranty


Product Code: E810CAM2-2CP
Qty:

Description


100 Gigabit Dual Port QSFP28 Intel E810-CAM2-BASED Low Latency Ethernet Network Interface Card

This dual-port 100Gb network interface card (NIC) is optimized on Intel E810-CAM2 controller for server connectivity and network virtualization. By supporting a PCIe 4.0 x16 host interface, this adapter provides sufficient bandwidth for line rate traffic on dual 100Gb ports.

Improved support for virtualization, including VMDq and SR-IOV, makes the NIC a perfect fit for virtualized environments. It is designed to provide broad interoperability, critical performance optimizations, and increased agility for communications, cloud, and enterprise IT network solutions.

Product Highlights

  • Data center with low-cost, low-power, 100GbE performance
  • 2x 100G QSFP28 ports (zQSFP)
  • Support RDMA (iWARP, RoCEv2) and IPsec offloading
  • House type data frame Max 9728b
  • Network virtualization SR-IOV, VxLAN, GENEVE, GRE
  • Data Plane Development Kit (DPDK) Optimized for Efficient Packet Processing


Specifications

Ports
Dual
Controller
Intel E810-CAM2
Supported Ethernet Speeds
100GbE
Host Interface
PCIe 4.0x16
Cabling Type
QSFP28 Transceiver, DAC and AOC
Link Rate
16 GT/s
Connectivity (VT-c)
Yes
OS Support
Windows, Linux, VMware, FreeBSD
Bracket Height
Tall & Short
Max. Power Consumption
20.8W
Storage Humidity
90% max. non-condensing relative humidity at 35ºC
Storage Temperature
-40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity
85% max. non-condensing relative humidity
Operating Temperature
0 °C to 55 °C (32 °F to 131 °F)
Card PCB Dimensions (WxD)
6.61x2.68" (168x68mm) (without bracket)
RoHS R6 Compliant
Yes
