SATA 3.0 6Gbps SATA to M.2 B+M Key SSD Enclosure

The SATA 3.0 6Gbps SATA to M.2 B+M Key SSD Enclosure is an external storage solution designed to convert M.2 SATA SSDs into portable external drives. This enclosure supports both B-key and M-key M.2 SATA SSDs, providing broad compatibility with various M.2 form factors. Utilizing the SATA 3.0 6Gbps interface, it delivers reliable data transfer speeds while offering a compact and portable design for easy transportation. The enclosure is ideal for users seeking to repurpose existing M.2 SATA SSDs or create high-performance external storage solutions for backup, data transfer, or expanded storage capacity.

Features

• Dual Key Support: Compatible with both M.2 B-key and M-key SATA SSDs
• SATA 3.0 Performance: Supports 6Gbps data transfer rates
• Tool-Free Design: Easy installation without requiring special tools
• Compact and Portable: Slim form factor for easy carrying and storage
• Plug-and-Play Operation: Simple USB connectivity for immediate use
• LED Activity Indicator: Visual status display for data transfer operations
• Aluminum Construction: Durable metal housing for effective heat dissipation

Specifications

• Product Model: SATA 3.0 6Gbps SATA to M.2 B+M Key SSD Enclosure
• Host Interface: USB 3.0 to SATA bridge
• Target Interface: M.2 B+M Key (SATA)
• Supported Form Factors: 2230, 2242, 2260, 2280
• Data Transfer Rate: Up to 6Gbps (SATA 3.0)
• Supported Protocols: SATA 3.0, USB 3.0
• Enclosure Material: Aluminum alloy
• Operating Temperature: 0°C to +50°C
• Power Supply: USB bus-powered
• LED Indicator: Blue activity LED
• Cable Included: USB 3.0 Type-A to Micro-B cable

Applications

• Portable Storage: Creating compact external drives for mobile use
• Data Backup: Reliable backup solution for important files and documents
• SSD Repurposing: Reusing older M.2 SATA SSDs as external storage
• Content Transfer: Fast file transfer between different computers and devices
• Gaming Storage: Expanding console or PC storage with portable SSDs
• Workstation Expansion: Additional storage for creative professionals
• System Migration: Data migration between systems using external storage
• Everyday Computing: General-purpose external storage for home and office use
