The Netgear GS516-300NAS is an unmanaged, 16-port Gigabit Ethernet switch designed for high-speed home and office networking, featuring a fanless design and energy-efficient operation.

General Specifications

• Product Type: Ethernet Switch
• Model: GS516v3
• Management Type: Unmanaged (plug-and-play)
• Layer Supported: 2
• Housing: Durable metal
• Cooling: Fanless (silent operation)
• Mounting Options: Desktop, wall-mountable, or 19-inch rackmount (kit included)

Performance & Connectivity

• Total Network Ports: 16 x RJ45 Gigabit Ethernet (10/100/1000Mbps)
• PoE Ports: None (N/A)
• Switching Capacity: 32 Gbps (non-blocking)
• Forwarding Rate: 14.88 Mpps (at 1000 Mbps port speed)
• Jumbo Frame Support: Up to 9 KB
• MAC Address Table Size: 8K entries
• Buffer Size: 512.5 KB (Packet buffer size)
• Supported Standards: IEEE 802.3i, 802.3u, 802.3ab, 802.3x (flow control), 802.3az (Energy Efficient Ethernet), 802.1p (QoS)

Power & Environmental

• Max Power Consumption: 10 W
• Power Source: Internal power supply, AC 100-240 V, 50-60 Hz
• Operating Temperature: 0 to 50°C (32 to 122°F)
• Dimensions (W x D x H): 328 x 169 x 43 mm (12.9 x 6.7 x 1.7 in)
• Weight: 1.5 kg (3.3 lb)
