The NETGEAR GS516UP-100NAS is a 16-port, unmanaged Gigabit Ethernet switch with 380W total PoE budget, featuring 8 ports that support PoE++ (up to 60W per port) and 8 ports that support PoE+. Its key specifications include a compact, desktop/rackmount form factor, 10/100/1000Mbps speeds, an 8K MAC address table, and a 9216-byte jumbo frame size.

Technical specifications

• Ports: 16 x RJ45 Gigabit Ethernet ports
• PoE: 8 x 802.3bt Ultra60 PoE++ ports and 8 x 802.3at PoE+ ports
• PoE Budget: 380W total
• Switch Type: Unmanaged
• Layer: Layer 2
• Data Transfer Rate: 10/100/1000Mbps per port
• MAC Address Table: 8K
• Jumbo Frames: 9216 bytes
• Buffer Memory: 192 KB
• Form Factor: Desktop / Rackmount

Physical and power

• Dimensions: 12.99" x 8.15" x 1.70" (approx. 330 x 207 x 43 mm)
• Weight: 5.73 lbs (2.60 kg)
• Power Input: 100–240V AC, 50/60Hz, 8–4A
