The Netgear GSM4248PX-100NAS is a 48-port,
fully managed AV switch with 40 Gigabit PoE+ ports and 8 10G SFP+ uplink ports.
It features a 960W PoE budget, supports Layer 3 networking, and comes
pre-configured with AV-specific settings for AV-over-IP deployments.
Its rear-facing ports and rack-mountable design are optimized for clean
integration into AV racks.

Key specifications

• Port
      configuration: 40 x 1Gb PoE+ ports and 8 x 10Gb SFP+ uplink ports


• PoE
      budget: 960W


• Switching
      fabric: 240 Gbps non-blocking


• Management: Fully
      managed with an AV-specific web GUI, supports profiles for Dante, AES67,
      AVB, and video protocols like NVX and Q-SYS


• Networking: Layer
      3 support, IGMP Plus for instant multicast streaming


• Console
      ports: USB-C and RJ45 RS232 console ports, plus a USB-A storage
      port


• Physical
      design: 1U rack-mountable with ports on the rear (or front, with
      a reversed mount), includes rack-mounting brackets for standard and
      recessed installation


• Cooling: Selectable
      fan modes for quiet or cool operation

Compatible Transceivers

The GSM4248PX-100NAS (Netgear M4250-40G8XF-PoE+) switch is
compatible SFP+ transceivers for its eight
10-Gigabit fiber ports.
