M.2 Key A.E. to PCIe 3.0 x16 Female Up R/A Extension Cable

The M.2 Key A.E. to PCIe 3.0 x16 Female Up R/A Extension Cable is a specialized interface conversion solution designed to enable PCIe expansion card connectivity through M.2 Key A+E interfaces with an upward-facing orientation. This adapter cable converts the limited PCIe lanes available in M.2 Key A+E slots into a standard PCIe 3.0 x16 female connector with an up right-angle configuration. The upward-facing orientation is particularly beneficial for systems where traditional horizontal card installation is not feasible or where optimal thermal management requires upward-facing cards. While the actual bandwidth is limited to the available lanes in the host M.2 interface, the physical x16 connector accommodates standard expansion cards, making this solution valuable for compact systems, specialized workstations, and custom computing applications with specific mechanical constraints.

Features

• M.2 Key A.E. Interface: Utilizes M.2 Key A+E slot for host connectivity
• PCIe 3.0 x16 Female Up R/A: Up right-angle PCIe x16 slot for expansion cards
• Upward Orientation: 90-degree upward-facing connector for specific layout requirements
• PCIe 3.0 Compatibility: Supports available PCIe lanes at 8.0 GT/s data rates
• Space-Optimized Design: Up right-angle connector addresses vertical space constraints
• Flexible Configuration: Enables PCIe card usage in systems without traditional slots
• Universal Compatibility: Works with various PCIe 3.0 expansion cards

Specifications

• Product Model: M.2 Key A.E. to PCIe 3.0 x16 Female Up R/A Extension Cable
• Host Interface: M.2 Key A+E Male
• Target Interface: PCIe 3.0 x16 Female Up Right-Angle
• Data Transfer Rate: Up to 8.0 GT/s per lane (bandwidth limited by available M.2 lanes)
• Supported Protocols: PCI Express 3.0
• Lane Configuration: PCIe x1 or x2 lanes (depending on host M.2 slot capability)
• Cable Type: Shielded flexible cable assembly
• Cable Length: 20cm, 30cm, 40cm
• Operating Temperature: 0°C to +70°C
• Connector Orientation: Up right-angle (90-degree upward)
• Power Delivery: Provides necessary power to connected PCIe devices

Applications

• Vertical Space-Constrained Systems: Computers where upward card orientation solves clearance issues
• Compact Workstations: Professional workstations requiring upward-facing card installation
• Custom PC Builds: Unique system configurations with specific orientation requirements
• All-in-One Computers: Expanding capabilities of integrated systems with upward card orientation
• Thermal Management: Systems where upward card positioning improves airflow and cooling
• Prototype Development: Testing and validation of PCIe devices in upward orientation
• Embedded Systems: Industrial applications requiring specific upward card mounting
• OEM Solutions: Custom implementations for products with specific mechanical and orientation requirements
