PCIe 3.0 M.2 NVMe Key-M Male to Left Bend M.2 NVMe Key-M Female SSD Extension Cable

The PCIe 3.0 M.2 NVMe Key-M Male to Left Bend M.2 NVMe Key-M Female SSD Extension Cable is a specialized interconnect solution engineered for challenging system layouts requiring left-oriented cable routing. This cable features a left-angle bend at the female connector, providing an optimal connectivity path for scenarios where right-angle solutions are not suitable. It enables efficient use of available space in compact systems while maintaining full PCIe 3.0 performance for NVMe storage devices. The left-bend design is particularly valuable for specific motherboard layouts, custom PC builds, and server configurations where cable routing constraints demand this unique orientation.

Features

• Left-Angle Connector Design: 90-degree left bend female connector for specific routing requirements
• PCIe 3.0 Performance: Supports data transfer rates up to 8.0 GT/s per lane
• Direction-Specific Solution: Addresses unique cable routing challenges in constrained spaces
• Optimized Cable Management: Enables clean installation in left-oriented system layouts
• Universal M.2 Support: Compatible with all standard M.2 SSD form factors
• Space-Efficient Configuration: Solves clearance issues where right-angle connectors are not suitable
• Reliable Connection: High-quality connectors ensure stable signal transmission

Specifications

• Product Model: PCIe 3.0 M.2 Key-M Male to Left Bend Female Extension Cable
• Host Connector: M.2 Key-M Male
• Device Connector: M.2 Key-M Female with 90-degree left bend
• Interface Support: PCIe 3.0 x4 lanes
• Data Transfer Rate: Up to 8.0 GT/s per lane (approximately 32 Gbps total bandwidth)
• Supported Protocols: NVMe 1.3, AHCI
• Bend Angle: 90-degree left turn
• Cable Type: Flexible shielded cable
• Cable Length: 8cm, 15cm, 20cm
• Operating Temperature: 0°C to +70°C
• Durability Rating: 3,000 mating cycles
• Minimum Bend Radius: 20mm

Applications

• Specific Layout Systems: Ideal for motherboards and cases requiring left-oriented cable routing
• Mirrored Configurations: Server setups and multi-system installations needing symmetrical cable management
• Custom PC Builds: Bespoke computing systems with unique internal layout requirements
• Space-Constrained Environments: Applications where right-angle solutions create interference
• OEM Integration: Pre-built systems requiring specific left-side connector orientation
• Test and Development: Prototyping storage configurations with directional constraints
• Upgrade Projects: Retrofitting NVMe storage into cases with specific clearance limitations
• Industrial Computers: Embedded systems and kiosks with fixed component placement
