M.2 NVMe Male Turn 180 Degree to PCIe 4.0 x16 Female Extension Cable, 85-ohm Low Impedance

The M.2 NVMe Male Turn 180 Degree to PCIe 4.0 x16 Female Extension Cable is a specialized high-performance adapter designed for complex system integration requiring complete directional reversal. This innovative cable features a standard M.2 NVMe male connector with a 180-degree turn that connects to a PCIe 4.0 x16 female slot. Engineered with precise 85-ohm impedance matching, this solution maintains excellent signal integrity at PCIe 4.0 data rates while providing a complete directional reversal for challenging spatial constraints. The 180-degree turn configuration enables sophisticated component placement in custom builds, specialized servers, and compact systems where traditional riser configurations cannot accommodate the mechanical requirements, making it ideal for applications where maximum connectivity flexibility is essential.

Features

• 180-Degree Turn Configuration: Complete directional reversal for extreme spatial constraints
• Standard PCIe 4.0 x16 Interface: Compatible with all PCIe 4.0 graphics cards and expansion devices
• Standard M.2 Interface: Compatible with regular M.2 NVMe Key-M slots
• PCIe 4.0 Performance: Supports full x16 lane bandwidth at 16 GT/s data rates
• Precision Impedance Control: 85-ohm characteristic impedance ensures signal integrity
• High-Speed Optimization: Engineered for minimal signal degradation at PCIe 4.0 frequencies
• Advanced Mechanical Design: Solves challenging clearance and routing problems in compact systems

Specifications

• Product Model: M.2 NVMe Male Turn 180 Degree to PCIe 4.0 x16 Female Extension Cable
• Host Connector: M.2 Key-M Male with 180-degree turn
• Device Connector: PCIe 4.0 x16 Female
• Interface Support: PCIe 4.0 x16
• Data Transfer Rate: Up to 16 GT/s per lane (approximately 256 Gbps total bandwidth)
• Supported Protocols: PCI Express 4.0, NVMe
• Characteristic Impedance: 85 ohms ±5%
• Turn Configuration: 180-degree directional change
• Cable Type: Shielded flexible cable
• Cable Length: 25cm, 35cm, 45cm
• Operating Temperature: 0°C to +70°C
• Insertion Loss: Optimized for PCIe 4.0 signal integrity requirements
• Durability Rating: 3,000 mating cycles
• Minimum Bend Radius: 40mm

Applications

• Complex Custom Builds: Computer modifications requiring 180-degree directional reversal for expansion cards
• Specialized Server Configurations: Unique server setups with specific spatial limitations
• Compact Workstation Solutions: Professional systems with extreme space constraints requiring innovative connectivity
• Prototype Development: Experimental computing configurations with severe spatial challenges
• OEM Manufacturing: Custom solutions for specific client integration requirements
• Testing and Validation: Specialized testing scenarios requiring 180-degree connector orientation
• High-Density Computing: Applications where maximum component density demands innovative connectivity solutions
• Industrial Systems: Embedded computing with fixed component placement and complex routing requirements
