PCIe 4.0 Mini PCIe Male to M.2 Key A WiFi Extension Cable

The PCIe 4.0 Mini PCIe Male to M.2 Key A WiFi Extension Cable is a specialized connectivity solution designed to bridge legacy Mini PCIe interfaces with modern M.2 Key A WiFi and wireless communication modules. This cable converts a Mini PCIe male connector to an M.2 Key A interface, enabling the integration of contemporary wireless technologies in systems originally designed for Mini PCIe expansion. Engineered to maintain PCIe 4.0 signal integrity, this adapter cable provides a reliable upgrade path for older systems while supporting various wireless communication protocols through the M.2 Key A interface specification.

Features

• Interface Conversion Technology: Bridges Mini PCIe male interface to M.2 Key A female connector with PCIe and USB signal compatibility
• M.2 Key A Compatibility: Supports M.2 Key A modules designed for WiFi, Bluetooth, NFC, and other wireless communication technologies
• PCIe 4.0 and USB Support: Maintains native PCIe 4.0 signaling for high-speed wireless modules while supporting USB 2.0 and other companion interfaces
• Enhanced Signal Integrity: Precision engineering with controlled impedance ensures stable data transmission for PCIe and auxiliary signals
• Secure Connection System: Reliable mating interfaces ensure stable operation and prevent accidental disconnection in various applications
• Modern Wireless Protocol Support: Enables integration of current wireless technologies into legacy systems with Mini PCIe expansion capabilities
• Compact Design: Space-efficient form factor suitable for installation in embedded systems and compact computing devices

Specifications

• Host Connector: Mini PCIe 52-pin Male
• Device Connector: M.2 Key A Female
• Supported Standard: PCI-SIG PCIe 4.0 Base Specification, M.2 Specification
• Key Support: Key A (A key compatible)
• Data Rate: 16.0 GT/s per lane (PCIe 4.0)
• Supported Protocols: PCIe x1, USB 2.0, I2C, UART, PCM
• Cable Type: Shielded twisted pair with overall braid protection
• Cable Length: 100mm, 150mm, 200mm standard options
• Operating Temperature: -20°C to +80°C
• Storage Temperature: -40°C to +85°C
• Durability Rating: 5,000 mating cycles minimum
• Contact Material: Gold-plated phosphor bronze

Applications

• Legacy System Modernization: Ideal for updating older industrial PCs and embedded systems with modern M.2 Key A wireless communication modules
• Wireless Connectivity Upgrades: Perfect for systems requiring integration of WiFi, Bluetooth, or other wireless technologies through M.2 Key A interfaces
• Industrial IoT Solutions: Supports wireless communication upgrades for industrial automation, control systems, and IoT gateways with Mini PCIe expansion
• Compact Computing Devices: Suitable for small form factor systems, mini-PCs, and embedded platforms requiring modern wireless capabilities
• Digital Signage and Kiosk Systems: Enables wireless functionality for commercial displays and interactive systems with Mini PCIe interfaces
• Prototyping and Development: Essential for engineering teams developing products that require interface conversion between Mini PCIe and M.2 Key A standards
• Test and Validation: Useful in laboratory environments for testing M.2 Key A wireless modules on Mini PCIe-based test platforms
• Custom Integration Projects: Provides flexible solutions for system integrators working with mixed-interface requirements and wireless communication upgrades
