PCIe 4.0 Mini PCIe Male to Mini PCIe Female Extension Cable

The PCIe 4.0 Mini PCIe Male to Mini PCIe Female Extension Cable is a specialized high-speed interconnect solution designed for extending Mini PCIe connectivity in compact computing systems and embedded applications. This cable provides a reliable electrical pathway from a Mini PCIe male connector to a Mini PCIe female interface, maintaining full PCIe 4.0 performance while enabling flexible component placement. Engineered for space-constrained environments, this extension solution is ideal for industrial computers, embedded systems, and compact devices requiring reliable signal extension for Mini PCIe expansion cards and modules.

Features

• Mini PCIe Interface Compatibility: Supports standard 52-pin Mini PCIe connectors for both host and device interfaces
• Full PCIe 4.0 Performance: Supports data rates up to 16 GT/s per lane, delivering maximum bandwidth for high-speed Mini PCIe devices
• Space-Optimized Design: Compact form factor enables installation in space-constrained embedded systems and compact computing devices
• Enhanced Signal Integrity: Precision engineering with controlled impedance ensures stable data transmission without signal degradation
• Secure Connection System: Robust Mini PCIe connectors with reliable mating mechanisms ensure stable operation in various orientations
• Universal Application Support: Compatible with various Mini PCIe devices including wireless cards, SSDs, and specialized expansion modules
• Flexible Installation: Enables optimal component positioning for improved thermal management and system integration

Specifications

• Host Connector: Mini PCIe 52-pin Male
• Target Connector: Mini PCIe 52-pin Female
• Supported Standard: PCI-SIG PCIe 4.0 Base Specification
• Data Rate: 16.0 GT/s per lane (PCIe 4.0)
• Total Bandwidth: 32 Gbps (x2 lanes typical for Mini PCIe)
• Supported Protocols: PCIe 4.0, USB 2.0, SMBus
• Cable Type: Shielded twisted pair with overall braid protection
• Cable Length: 100mm, 150mm, 200mm standard options
• Operating Temperature: -20°C to +80°C
• Storage Temperature: -40°C to +85°C
• Durability Rating: 5,000 mating cycles minimum
• Contact Material: Gold-plated phosphor bronze

Applications

• Embedded Systems: Ideal for industrial embedded computers and single-board computers requiring extended Mini PCIe connectivity
• Industrial Automation: Perfect for industrial control systems and manufacturing equipment needing flexible component placement
• Compact Computing Devices: Suitable for small form factor PCs, thin clients, and compact workstations with space constraints
• Communications Equipment: Supports wireless communication modules and network interface cards in networking devices
• Digital Signage Solutions: Enables flexible component integration in digital signage players and kiosk systems
• Test and Development: Essential for laboratory environments requiring flexible Mini PCIe card positioning for validation and testing
• Medical Devices: Appropriate for medical equipment and diagnostic systems requiring reliable Mini PCIe extension
• Transportation Systems: Supports computing applications in automotive, aviation, and transportation systems with compact form factors
