Mini PCIe Male to PCIe 4.0 x4 Female Down R/A Extension Cable

The Mini PCIe Male to PCIe 4.0 x4 Female Down R/A Extension Cable is a specialized connectivity solution designed to bridge legacy Mini PCIe interfaces with modern PCIe 4.0 x4 expansion capabilities while providing space-optimized downward connector orientation. This cable converts a Mini PCIe male connector to a PCIe 4.0 x4 female interface with a Down Right-Angle configuration, enabling the use of compatible expansion cards with Mini PCIe-based systems in space-constrained environments. Engineered to maintain PCIe 4.0 signal integrity, this adapter solution provides a performance upgrade path for older systems while offering efficient cable management through its downward-angled connector design for various computing applications.

Features

• Interface Conversion Technology: Bridges Mini PCIe male interface to PCIe 4.0 x4 female connector with PCIe 4.0 signal compatibility
• Down Right-Angle Connector Design: PCIe 4.0 x4 female connector with downward orientation facilitates space-efficient installation in low-clearance environments
• PCIe 4.0 Performance Support: Maintains native PCIe 4.0 signaling supporting data rates up to 16 GT/s per lane for compatible expansion cards
• Enhanced Signal Integrity: Precision engineering with controlled impedance ensures stable data transmission between different interface generations
• Secure Connection System: Robust mating interfaces ensure reliable operation for various expansion card applications
• Space-Optimized Solution: Combines compact Mini PCIe interface with downward-angled x4 connector for installations with limited vertical clearance
• Legacy System Enhancement: Enables integration of modern PCIe 4.0 x4 expansion cards into systems with Mini PCIe interfaces

Specifications

• Host Connector: Mini PCIe 52-pin Male
• Target Connector: PCIe 4.0 x4 Female, Down Right-Angle orientation
• Supported Standard: PCI-SIG PCIe 4.0 Base Specification
• Data Rate: 16.0 GT/s per lane (PCIe 4.0)
• Total Bandwidth: 64 Gbps (x4 lanes)
• Supported Protocols: PCIe 4.0, backward compatible with PCIe 3.0/2.0
• Cable Type: Shielded construction with EMI protection
• Cable Length: 150mm, 200mm, 250mm standard options
• Operating Temperature: -20°C to +80°C
• Storage Temperature: -40°C to +85°C
• Durability Rating: 5,000 mating cycles minimum
• Contact Material: Gold-plated contacts

Applications

• Space-Constrained Legacy Systems: Ideal for updating older industrial PCs and embedded systems with PCIe 4.0 x4 expansion capabilities where vertical space is limited
• Compact Computing Platforms: Perfect for small form factor systems and low-profile devices requiring x4 expansion card support with downward cable routing
• Industrial Control Systems: Supports expansion card integration in industrial automation and control equipment with space constraints
• Prototyping and Development: Essential for engineering teams developing products that require interface conversion between Mini PCIe and PCIe 4.0 x4 standards in confined spaces
• Test and Validation Environments: Useful in laboratory settings for testing PCIe 4.0 x4 expansion cards on Mini PCIe-based test platforms with specific orientation requirements
• Low-Profile Embedded Solutions: Enables expansion card capabilities in embedded systems where downward connector orientation is necessary for proper integration
• Custom Integration Projects: Provides flexible solutions for system integrators working with mixed-interface requirements and specific spatial limitations
• Portable Computing Equipment: Suitable for mobile and portable computing applications where compact interface conversion and downward cable routing are beneficial
