PCIe 4.0 x16 Male Turn 180 Degree to x16 Female Extension Cable

The PCIe 4.0 x16 Male Turn 180 Degree to x16 Female Extension Cable is an advanced interconnect solution designed for computing systems requiring complete GPU orientation reversal while maintaining optimal signal integrity. This specialized cable features a 180-degree male connector combined with a standard female connector, enabling complete directional reversal of graphics card mounting while preserving full PCIe 4.0 performance. Engineered for custom PC builds, specialized workstations, and spatially constrained environments, this extension solution addresses challenging installation scenarios where complete component direction change is necessary for optimal system layout and thermal management.

Features

• Complete 180-Degree Orientation: Male connector with full 180-degree turn enables complete GPU direction reversal for flexible system configurations
• Full PCIe 4.0 Performance: Supports data rates up to 16 GT/s per lane, delivering total bandwidth of 256 Gbps for high-performance graphics cards and accelerators
• Enhanced Signal Integrity: Precision engineering with controlled impedance ensures stable data transmission through the 180-degree cable path
• Advanced Installation Flexibility: 180-degree male connector facilitates installations where complete component reversal is required for optimal layout
• Reinforced Construction: High-quality materials and robust strain relief provide durability in permanent installations and frequent reconfigurations
• Comprehensive EMI Shielding: Multi-layer electromagnetic protection maintains signal quality through the extended cable path
• Universal Compatibility: Supports all PCIe 4.0 compatible devices while maintaining backward compatibility with previous PCIe generations

Specifications

• Host Connector: PCI Express 4.0 x16 Male with 180-degree turn
• Target Connector: PCIe 4.0 x16 Female, standard orientation
• Supported Standard: PCI-SIG PCIe 4.0 Base Specification
• Data Rate: 16.0 GT/s per lane (PCIe 4.0)
• Total Bandwidth: 256 Gbps (x16 lanes)
• Cable Configuration: 180-degree turn at male connector
• Cable Type: Shielded twisted pair with reinforced construction
• Cable Length: 200mm, 250mm, 300mm standard options
• Operating Temperature: 0°C to +70°C
• Storage Temperature: -40°C to +85°C
• Durability Rating: 10,000 mating cycles
• Contact Material: Gold-plated phosphor bronze

Applications

• Custom Case Modifications: Essential for modified computer cases requiring complete GPU orientation reversal for optimal internal layout
• Complex System Integrations: Ideal for specialized workstations and servers where component positioning demands complete direction change
• Space-Constrained Installations: Perfect for environments with severe spatial limitations where traditional cable routing cannot accommodate component placement
• Advanced Cooling Solutions: Supports complex cooling configurations where radiator placement and airflow management necessitate GPU reversal
• Prototype and Development Systems: Valuable for engineering prototypes and testing platforms requiring flexible component orientation for comprehensive validation
• Industrial Computing Applications: Suitable for industrial PCs and embedded systems where internal layout optimization requires component direction reversal
• Showcase and Exhibition Computers: Excellent for demonstration systems and display PCs where unique component orientation enhances visual impact
• Aesthetic-Focused Builds: Enables creative visual presentations in showcase PCs where unconventional component orientation creates distinctive aesthetic appeal
