M.2 NVMe Male Right Bend to PCIe 5.0 x16 Female Up R/A FFC Extension Riser Cable

The M.2 NVMe Male Right Bend to PCIe 5.0 x16 Female Up R/A FFC Extension Riser Cable is a specialized high-speed adapter designed for advanced system integration requiring right-oriented connectivity solutions. This innovative cable features a right-bend M.2 NVMe male connector combined with a PCIe 5.0 x16 female up right-angle slot, utilizing Flat Flexible Cable technology to deliver maximum flexibility in space-constrained environments. The right-angle configuration at both ends enables optimal GPU placement and cable routing in custom computer builds, small form factor systems, and specialized computing applications where traditional straight connectors are not feasible. This solution maintains full PCIe 5.0 bandwidth while providing exceptional mechanical flexibility for challenging installation scenarios.

Features

• Right-Bend M.2 Connector: 90-degree right-oriented M.2 male connector for specific spatial requirements
• PCIe 5.0 x16 Performance: Delivers full x16 lane bandwidth at 32 GT/s data rates
• Up Right-Angle PCIe Slot: 90-degree upward-facing PCIe x16 slot for optimal graphics card orientation
• Advanced FFC Construction: Ultra-thin flat flexible cable enables complex routing in tight spaces
• High-Speed Signal Integrity: Precision engineering preserves PCIe 5.0 signal quality
• Space-Optimized Design: Solves clearance issues in compact system configurations
• Enhanced Cooling Compatibility: Right-angle design improves airflow management around critical components

Specifications

• Product Model: M.2 NVMe Male Right Bend to PCIe 5.0 x16 Female Up R/A FFC Riser Cable
• Host Connector: M.2 Key-M Male with 90-degree Right Bend
• Device Connector: PCIe 5.0 x16 Female Up Right-Angle
• Cable Type: Flat Flexible Cable (FFC)
• Interface Support: PCIe 5.0 x16
• Data Transfer Rate: Up to 32 GT/s per lane (approximately 512 Gbps total bandwidth)
• Supported Protocols: PCI Express 5.0, NVMe
• Cable Length: 18cm, 25cm, 35cm
• Cable Thickness: 0.3mm maximum
• Operating Temperature: 0°C to +70°C
• Characteristic Impedance: 85 ohms ±5%
• Durability Rating: 12,000 bending cycles
• Minimum Bend Radius: 5mm

Applications

• Small Form Factor Gaming PCs: High-performance GPU integration in compact cases
• Custom Water-Cooling Systems: Flexible GPU positioning for complex liquid cooling loops
• Mini-ITX Workstations: Professional graphics capability in minimal footprint systems
• Cryptocurrency Mining Rigs: Space-optimized multi-GPU configurations
• Test and Development Environments: Flexible GPU connectivity for validation and prototyping
• OEM Server Solutions: Custom server configurations with specific expansion requirements
• High-Density Computing: Maximizing component density in rack-mounted systems
• Aesthetic PC Builds: Showcase systems requiring precise component placement and clean cable management
