The Ubiquiti UniFi US-8-60W is an 8-port Gigabit switch with 4 ports supporting IEEE 802.3af Power over Ethernet (PoE), providing up to 15.4W per port and a total PoE budget of 48W. It offers 8 Gbps non-blocking throughput, 16 Gbps switching capacity, and includes an external AC/DC adapter for power. The switch features an SGCC steel enclosure, operates in temperatures from -5 to 45°C, and supports features like VLANs, storm control, and port mirroring.

Key Specifications

• Networking Interface: 8 x 10/100/1000 Mbps RJ45 Ports
• PoE Ports: 4 x 10/100/1000 Mbps RJ45 Ports (Ports 5, 6, 7, 8)
• PoE Standard: IEEE 802.3af
• Max. PoE Wattage per Port: 15.4W
• Total PoE Availability: 48W
• Total Non-Blocking Throughput: 8 Gbps
• Switching Capacity: 16 Gbps
• Forwarding Rate: 11.9 Mpps
• Dimensions: 148 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21")
• Weight: 432 g (15.24 oz)
• Enclosure: SGCC Steel
• Power Method: External 48VDC, 1.25A AC/DC adapter
• Max. Power Consumption: 12W (Excluding PoE Output)

Features

• Compact Form Factor: Suitable for desktop or wall mounting.
• Managed Features: Supports VLANs, LACP, STP/RSTP, DHCP Snooping, IGMP Snooping, Port Isolation, Port Mirroring, and Flow Control.
• PoE Standard: Specifically supports IEEE 802.3af (PoE), not the higher-power 802.3at (PoE+) standard.
• Included Accessories: Comes with an external AC/DC power adapter.
