The Ubiquiti UniFi Switch USW-Pro-24-PoE is a 24-port, rack-mountable, managed Layer 3 switch offering 22 Gigabit Ethernet ports (some PoE++ capable) and 2 10G SFP+ ports for 10 Gbps uplinks. It features a 450W internal power supply with a redundant power option via a USP RPS DC input, and supports PoE standards including IEEE 802.3af, IEEE 802.3at (PoE+), and IEEE 802.3bt (PoE++). The switch includes Layer 3 features such as inter-VLAN routing and DHCP server functionality and is managed via the UniFi Network Application.

Key Specifications

• Ports:
• 22 x 1 Gbps RJ45 ports
• 2 x 10 Gbps SFP+ ports
• PoE:
• Supports 802.3af, 802.3at, and 802.3bt PoE standards
• Four ports provide up to 64W of PoE++
• PoE Power Budget: 400W (with some sources stating 450W)
• Layer 3 Features: Inter-VLAN routing, static routing, DHCP server
• Uplink: 10 Gbps via SFP+ ports
• Management: UniFi Network Application (web and mobile)
• Power:
• Internal 450W power supply
• Redundant power option via USP RPS DC input
• Dimensions: 442.4 x 285.4 x 43.7 mm (17.4 x 11.2 x 1.7 inches)
• Cooling: Near-silent cooling with PWM-controlled fans and temperature sensors
• Form Factor: 1U, rack-mountable
