Cisco AIR-AP1832I-S-K9 Aironet 1832I 802.11ac Wave 2 AP, 3x3:2, Internal Antenna, S Regulatory Domain

AIR-AP1832I-S-K9 is one of the Cisco Aironet 1830 Series Access Points. Cisco 1830 AP series is ideal for small and medium-sized networks. This series supports the latest Wi-Fi standard, the 802.11ac Wave 2 standard. The 1830 Series extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support. The model AIR-AP1832I-S-K9 provides S Regulatory Domain and internal antennas.

Specifications

• Part Number: AIR-AP1832I-S-K9
• Description: 802.11ac Wave 2 AP, 3x3:2, Internal Antenna, S Regulatory Domain
• Features
• 3x3 MIMO with two spatial streams, single-user or multiuser MIMO
• MRC
• 802.11ac beamforming (transmit beamforming)
• 20-, 40-, and 80-MHz channels
• PHY data rates up to 867 Mbps (80 MHz in 5 GHz)
• Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
• 802.11 DFS
• CSD support
• Regulatory Domain
• S (S regulatory domain):

• 2.412 to 2.472 GHz; 13 channels
• 5.180 to 5.320 GHz; 8 channels
• 5.500 to 5.700 GHz;, 11 channels
• 5.745 to 5.825 GHz; 5 channels
• Integrated antenna
• 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360°
• 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360°
• Interfaces
• 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE)
• Management console port (RJ-45)
• USB 2.0 (enabled via future software)
• Dimensions (W x L x H): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm)
• Weight: 3.12 lb (1.41 kg)
