Dell AOC-QSFP-100G-30M 100G-AOC QSFP28 to QSFP28 30m Active Optical Cable 038-004-661-01

This Dell AOC-QSFP-100G-30M uses a new generation of technologies to accept the same electrical input as conventional copper cables, but it uses fiber between connectors to achieve a variety of advantages, including longer distances and higher bandwidth to achieve rapid and effective data transfer. It is suitable for short-distance high-speed data interconnection within data centers, enterprise cores, distribution layers, and high-performance computing applications.

Features

• Four-channel full-duplex active optical cable
• Multirate capability: 10Gb/s to 25Gb/s per channel
• QSFP28 high-density form factor
• Low power dissipation: <3.5W per cable end
• Low weight for high-port-count architectures
• Allow different equipment connect by configuring each end of the cable

Specifications

• Brand: Dell
• Part Number(s): AOC-QSFP-100G-30M, 038-004-661-01
• Form Factor: QSFP28 AOC
• Max Data Rate: 100 Gb/s
• Wavelength: 850 nm
• Supply Voltage: 3.3V
• Cable Color: Aqua
• Fiber Type: OM3
• Cable Length: 30 meter (98.4 ft)
• Cable Diameter: 3 mm
• Minimum cable bend radius: 25 mm
• Cable Jacket Type: LSZH
• Connector: QSFP28 to QSFP28
• Digital Diagnostic Monitoring: Yes
• Environment
• Operating: 0°C to 70°C
• Storage: -40°C to 85°C
• Weight: 0.75 kg
• Applications
• 100G Ethernet transmission
• Infiniband FDR, EDR
• Proprietary High-Speed Interconnections
• High-performance computing clusters
• Fibre Channel
