Conserve valuable PCI Express* (PCIe*) server slots while adding multi-port Gigabit Ethernet capability with the Intel PRO/1000 PT Quad Port LP Server Adapter. The dedicated input/output (I/O) bandwidth of PCIe* ensures priority performance on each port–without bus sharing–for Gigabit Ethernet connectivity in Category-5 networks. The Intel PRO/1000 PT Quad Port LP Server Adapter improves performance in multi-processor systems by balancing network loads across multiple central processing units (CPUs). Additionally, the Intel PRO/1000 PT Quad Port LP Server Adapter supports Intel I/O Acceleration Technology (Intel I/OAT) for faster I/O processing on the new quad-core and dual-core Intel Xeon processor-based servers.
Features - Four high-performance PCI Express* 10/100/1000 Mbps connections for slot-constrained servers requiring high bandwidth
- Multi-gigabit ethernet scalability enhances and increases uptime through advanced server features
- Built on Intel lead-free technology
Specifications - Product Name: Intel PRO/1000 PT Quad Port LP Server Adapter
- Product Code: EXPI9404PTL
- Connectors: Four RJ-45
- IEEE standards/network topology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Wiring: Category-5, UTP, 4-pair
- Cable distance: 100 m in Category-5 for 100/1000 Mbps; Category-3 for 10 Mbps
- Data rate(s) supporter per port: 10, 100, and 1000 Mbps
- Bus type: PCI Express 1.0a
- Bus width: x4 Lane PCI Express, operable in x4,x8, x16 slots
- Bus speed (x1, encoded rate): 10 Gbps uni-directional; 20 Gbps bi-directional
- EEPROM-SPI and single EEPROM support: Yes
- Interrupt levels: INTA, INTB, INTC, INTD
- IEEE support: 802.3ab*
- Hardware certifications: FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
- Controller-processor: Intel 82571GB
- Typical power consumption: 12.096 W (12 V @ 1.008 A)
- Operating temperature: 0-55° C
- LEDs: 4 (1/port, link and speed) solid and blinking
Physical Dimensions - Length: 16.77 cm (6.601 in)
- Width: 6.89 cm (2.713 in)
- Height of end bracket: 8.00 cm (3.153 in)
Network Operating Systems (NOS) Software Support - Microsoft Windows* Server 2003, Enterprise, Datacenter (32- & 64-bit)
- Microsoft Windows 2000
- Red Hat Linux* 2.4x or later (32- and 64-bit)
- FreeBSD 4.x or later
- Novell Netware* 5.x, 6.x
- Sun Solaris* x86, OS 8 and later
- SCO Open Server 5, OpenUNIX 8
|
|
|
 |
|
 |
|
