Intel 10 Gigabit XF SR Server Adapter, Single Port, LC MMF, 10GbE, PCIe, 82598EB
Genuine HPE J9736A

Alternative Views:
Our Price: $200.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days
Brand: Intel
Condition: New Factory Sealed


Product Code: EXPX9501AFXSR
Qty:

Description

Based on the Intel 82598EB 10 Gigabit Ethernet controller, the next-generation Intel 10 Gigabit XF SR Server Adapters are designed to meet the throughput and latency requirements of bandwidth-hungry applications, while offering a very low power envelope for energy efficiency. Ideal for slot-constrained environments, the Intel10 Gigabit XF SR Dual Port Server Adapter provides a simplified alternative to multiple 1 Gbps server adapters.

Features
  • Intel 82598EB 10 Gigabit Ethernet Controller
  • Low profile
  • Load balancing on multiple CPUs
  • Intel I/O Acceleration Technology (Intel I/OAT)
  • iSCSI remote boot support
  • MSI-X support
  • Virtual Machine Device queues1 (VMDq)
  • Low latency
  • Optimized queues: 32 Transmit (Tx) and 64 Receive (Rx) per port
  • Compatible with x4, x8, and x16 standard and low-profile PCI Express slots
  • Support for most Network Operating Systems (NOS)
  • Remote management support
  • Multi-mode fiber 62.5/50 µm
  • RoHS compliant, lead-free technology
  • Intel PROSet Utility for Microsoft Windows Device Manager
  • Intel backing

Specifications
  • Product Name: Intel 10 Gigabit XF SR Server Adapter
  • Product Code: EXPX9501AFXSR
  • Market Segment: Server
  • Bracket Height: Low-Profile (LP) / Full-Height (FH)
  • Connectors: IEEE standards/network topology 10GBASE-SR one LC fiberoptic connector
  • Cabling: Multi-mode fiber (62.5 µm or 50 µm)
  • Data rate(s) supported per port: 10 Gigabit
  • Bus type: PCI Express 2.0
  • Bus width: x8 lane PCI Express, operable in x4, x8, x16 slots
  • Bus speed (x8, encoded rate): 20 Gbps uni-directional; 40 Gbps bi-directional
  • Interrupt levels: INTA, MSI, MSI-X
  • Hardware certifications: FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
  • Controller-processor: Intel 82598EB
  • Typical power consumption: 10.4W (0.87A @ 12V);
  • Operating temperature: 0° C to 55° C (32° F to 131° F) Single Port with 100 LFM forced-air flow (linear feet per minute)
  • Storage temperature: -40° C to 70° C (-40° F to 158° F)
  • Storage humidity: 90% non-condensing relative humidity at 35° C
  • LEDs: 1, LINK (solid), and ACTIVITY (blinking)
  • Physical Dimensions
    • Length: 16.74 cm (6.59 in)
    • Width: 6.89 cm (2.71 in)
    • Height of end bracket
      • PCI Express standard, 12 cm (4.725 in);
      • PCI Express low-profile, 7.92 cm (3.12 in)
