FiberHome FH-C2725L-CD10 25G 1271nm 10km CWDM SFP28 Transceiver Module
FH-C2725L-CD10 - Genuine FiberHome FH-C2725L-CD10

Alternative Views:
Our Price: $100.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: FH-C2725L-CD10
Qty:

Description

This FiberHome FH-C2725L-CD10 SFP28 transceiver provides 25GBase-CWDM throughput up to 10km over single mode fiber (SMF) using a wavelength of 1270nm via an LC duplex connector. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard.

Specifications
  • Form Factor: SFP28
  • Max Data Rate: 25.8Gbps
  • Wavelength: 1271nm
  • Max Cable Distance: 10km
  • Connector: LC duplex
  • Media: SMF
  • Transmitter Type: DFB CWDM
  • Receiver Type: PIN
  • DDM/DOM: Supported
  • Commercial Temperature Range: 0 to 70°C (32 to 158°F)
  • TX Power: 0~6dBm
  • Receiver Sensitivity: <-14dBm
  • Power Consumption: 1.3W
  • Extinction Ratio: 3.5dB
  • Modulation Format: NRZ
  • CDR: TX and RX
  • Transmit and Dispersion Penalty: 1dB
  • Powerbudget: 14dB
  • Packaging Technology: TO-CAN Packaging
  • FEC Function: Not Supported
  • Protocols: MSA Compliant, CPRI, eCPRI
  • Application: 25GBASE Ethernet, Data Center, Telecom
