Finisar FTLC1122RDNL 100GBASE-LR4 10km Gen2 CFP2 Optical Transceiver

Our Price: $1,200.00

Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days

Product Code: FTLC1122RDNL

Qty:

Description

FTLC1122RDNL second-generation 100G CFP2 transceiver modules are designed for use in 100 Gigabit Ethernet interfaces over single mode fiber. They are compliant with the CFP MSA and IEEE 802.3ba 100GBASE-LR4 specifications. Digital diagnostics functions are available via an MDIO interface, as specified by the CFP MSA and Application Note AN-2118. The optical transceiver is RoHS compliant as described in Application Note AN-2038.

Features

Hot-pluggable CFP2 form factor
Supports 103.1Gb/s aggregate bit rate
Power dissipation < 5W
RoHS compliant
Commercial case temperature range of 0°C to 75°C
Single 3.3V power supply
Maximum link length of 10km on Single Mode Fiber (SMF)
4x26Gb/s DFB-based LAN-WDM transmitter
4x26G electrical interface
Duplex LC receptacles
MDIO management interface

Applications

100GBASE-LR4 100G Ethernet

Specifications

Distance: 10 km
Data Rate (max): 103.1 Gb/s
Protocol: 100G Ethernet Compliant
Low End Case Temperature (°C): 0
High End Case Temperature (°C): 75
Diagnostics: Digital
Transmitter: 4x LWDM DFB Laser
Receiver: PIN
Voltage Supply: 3.3
Connector: LC
Wavelength: 1310nm Band
