Finisar FTLF1217P2BTL 100BASE-FX 2km SFP Optical Transceiver
Genuine Finisar FTLF1217P2BTL

Alternative Views:
Our Price: $160.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: FTLF1217P2BTL
Qty:

Description

FTLF1217P2BTL Small Form Factor Pluggable (SFP) transceivers are compatible with the SFP Multi-Sourcing Agreement (MSA). They are simultaneously compatible with 100Base-FX, FDDI, ESCON, and Multimode SONET OC-3 SR-0 and OC-1 SR-0 standards as specified in IEEE Std 802.3, ISO/IEC 9314-3, Enterprise Systems Architecture/390, and ANSI T1.416.01-1999, respectively. The optical transceiver is RoHS compliant as described in Application Note AN-2038. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA.

Features
  • Up to 200 Mb/s bi-directional data links
  • Hot-pluggable SFP footprint
  • Built-in digital diagnostic functions
  • 1310nm LED-based transmitter
  • Duplex LC connector
  • RoHS compliant
  • Up to 2km on 62.5/125?m MMF
  • Metal enclosure, for lower EMI
  • Single 3.3V power supply
  • Low power dissipation
  • Industrial operating temperature range: -40°C to 85°C

Applications
  • 125 Mb/s 100Base-FX Ethernet/FDDI
  • 200 Mb/s ESCON
  • 155 Mb/s Multimode SONET OC-3 SR-0
  • 51 Mb/s Multimode SONET OC-1 SR-0

Specifications
  • Distance: 2km
  • Data Rate (max): 200 Mb/s
  • Protocol: Optical Fast Ethernet Compliant SONET OC-3 Compatible
  • Low End Case Temperature (°C): -40
  • High End Case Temperature (°C): 85
  • Diagnostics: Digital
  • Transmitter: LED
  • Receiver: PIN
  • Voltage Supply: 3.3
  • Connector: LC
  • Wavelength: 1310nm
