The new Intel® Ethernet Server Adapter I350 family builds on Intel’s history of excellence in Ethernet products. Intel continues its market leadership with this new generation of PCIe* gigabit Ethernet (GbE) network adapters. Built with the bridgeless Intel® Ethernet Server Adapter I350, these adapters represent the next step in the GbE networking evolution for the enterprise and data center by introducing new levels of performance through industry-leading enhancements for both virtualized and iSCSI unified networking environments. This new family of adapters also includes new power management technologies, such as energy-efficient Ethernet and direct memory access coalescing.
Essentials - Product P/N: I350-F4
- Product Collection: Gigabit Ethernet Adapters (up to 2.5GbE)
- Launch Date: Q4'11
- Vertical Segment: Server
- Cable Medium: Fiber
- Cabling Type: MMF 50um up to 550m; MMF 62.5um up to 275m
- Bracket Height: Full height
- TDP: 6 W
- Product Order Code: I350F4, I350F4BLK
- Supported Operating Systems: Windows Server 2016*, Windows Server 2012 R2*, Windows Server 2012*, Windows 10*, Windows 8*, Windows Server 2008 R2*, Windows 7*, Windows Server 2008*, Windows Vista*, Windows Server 2003 R2*, Windows Server 2003*, Windows XP Professional, Linux* Stable Kernel version 3.x, 2.6,x, Red Hat Enterprise Linux* 5, 6, SUSE Linux Enterprise Server* 10, 11, FreeBSD 9*, VMware ESX/ESXi
Networking Specifications - Port Configuration: Quad
- Intel® Virtualization Technology for Connectivity (VT-c): Yes
- Speed & Slot Width: 5 GT/s x 4 Lane
- Controller: Intel I350
Package Specifications - System Interface Type: PCIe v2.1 (5.0 GT/s)
Intel® Virtualization Technology for Connectivity - On-chip QoS and Traffic Management: Yes
- Flexible Port Partitioning: Yes
- Virtual Machine Device Queues (VMDq): Yes
- PCI-SIG* SR-IOV Capable: Yes
Advanced Technologies - iWARP/RDMA: No
- Intel® Ethernet Power Management: Yes
- Intelligent Offloads: Yes
- Storage Over Ethernet: iSCSI, NFS
|
|
 |
 |
 |
 |

|
