Mellanox MFM1T02A-SR SFP+ optical module for 10GBASE-SR
MFM1T02A-SR - NVIDIA Mellanox

Alternative Views:
Our Price: $45.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: MFM1T02A-SR
Qty:

Description Datasheet

10GbE SFP+ MMF Optical Transceiver

The Mellanox MFM1T02A-SR is a pluggable, SFP+ optical transceiver, designed for use in 10GbE Ethernet systems. The transceiver operates over multi-mode (MMF) fiber, using a nominal wavelength of 850nm, and is SFF-8083 compliant.

MFM1T02A-SR has an IEEE 802.3ae compliant standard SFP+ interface on the electrical side towards the host system. The optical interface is composed of two optical channels/fibers, intended for connection of an MMF cable via a standard LC connectors.

Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability

Highlights
  • Up to 10.3125Gb/s data rate
  • SFF-8083 compliant
  • IEEE 802.3ae 10GBASE-SR compliant
  • 1W maximum power consumption
  • 3.3V power supply
  • BER better than 1E-15
  • Operating case temperature of 0-70°C
  • Hot pluggable
  • Class 1 laser safety
  • Up to 300m link length on OM3 multimode fiber at 10Gb/s
  • Up to 400m link length on OM4 multimode fiber at 10Gb/s
  • RoHS compliant
  • SFF-8083 compliant management interface
  • SFF-8472 compliant digital diagnostic monitoring (DDM)

Specifications
  • Configuration: 10GbE SR
  • Configuration: SFP+
  • Application: 1x 10G-NRZ Serial
  • Connector: 2-fiber duplex LC
  • Max Reach: 400m
  • Wavelength: 850nm multi-mode
  • Part Number: MFM1T02A-SR
