NVIDIA Mellanox MFM1T02A-T Compatible 10GBASE-T SFP+ Copper RJ-45 30m Optical Transceiver Module

This Mellanox MFM1T02A-T SFP+ transceiver provides 10GBase-T throughput up to 30m over cat6a/cat7 copper cable via RJ-45 connector. This transceiver is compliant with IEEE 802.3an, IEEE 802.3az, SFF-8431 and SFP+ MSA. Featuring low power consumption, this easy to install, hot swappable 10G SFP+ transceiver is ideal for enterprise networking for LAN applications and different other networking places using copper connections.

Specifications

• Brand: Compufox
• Part Number: MFM1T02A-T
• Form Factor: SFP+
• Max Data Rate: 10Gbps
• Power Consumption: ?2.3W
• Cable Distance: 30m@Cat6a/Cat7 or Better
• Connector: RJ-45
• Cable Type: Copper
• DDM/DOM: Not Supported
• EMC (Electro Magnetic Compatibility): Supported
• Operating Temperature: Commercial - 0 to 70°C (32 to 158°F)
• Protocols: IEEE 802.3an, IEEE 802.3az, SFP+ MSA, SFF-8431
