Mellanox MMS1V50-WM 400GBASE-FR4 QSFP-DD PAM4 1310nm 2km DOM Duplex LC SMF Optical Transceiver Module

The MMS1V50-WM 400GBASE-FR4 module supports link lengths of up to 2km SMF with duplex LC connector. It is compliant to IEEE 802.3bs, 400GBASE-FR4 Spec of 100G Lambda MSA group, and 400GAUI-8/CEI-56G-VSR-PAM4 standards. The 400 Gigabit Ethernet signal is carried over four CWDM grid optical wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device.

Specifications

• Brand: Mellanox
• Part Number: MMS1V50-WM
• Form Factor: QSFP-DD
• Max Data Rate: 400Gbps
• Wavelength: 1271nm,1291nm,1311nm,1331nm
• Max Cable Distance: 2km
• Connector: Duplex LC
• Media: SMF
• Transmitter Type: CWDM EML
• Receiver Type: PIN
• TX Power: -3.3~3.5dBm
• Receiver Sensitivity: < -7.3dBm
• Powerbudget: 4dB
• Receiver Overload: 3.5dBm
• Power Consumption: ? 12W
• Extinction Ratio: 3.5dB
• DDM/DOM: Supported
• Commercial Temperature Range: 0 to 70°C (32 to 158°F)
• DSP: TX and RX
• Host FEC: Supported
• Protocols: QSFP-DD MSA Compliant
