Mellanox MMS1V90-WR 400GBASE-LR4 QSFP-DD PAM4 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module

The MMS1V90-WR 400GBASE-LR4 module supports link lengths of up to 10km over a standard pair of G.652 single mode fiber (SMF) with duplex LC connectors. It is compliant to IEEE 802.3bs protocol and 400GAUI-8/CEI-56G-VSR-PAM4 standard. The 400 Gigabit Ethernet signal is carried over four CWDM grid optical wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device.

Specifications

• Brand: Mellanox
• Part Number: MMS1V90-WR
• Form Factor: QSFP-DD
• Max Data Rate: 400Gbps
• Wavelength: 1271nm,1291nm,1311nm,1331nm
• Max Cable Distance : 10km
• Connector: Duplex LC
• Media: SMF
• Transmitter Type: CWDM EML
• Receiver Type: PIN
• TX Power: -2.8~4.0dBm
• Receiver Sensitivity: <-9.1dBm
• Powerbudget: 6.3dB
• Receiver Overload: 4.0dBm
• Power Consumption: ?12W
• Extinction Ratio: 3.5dB
• DDM/DOM: Supported
• Commercial Temperature Range: 0 to 70°C (32 to 158°F)
• DSP: TX and RX
• Host FEC: Supported
• Protocols: QSFP-DD MSA Compliant
