HPE B-SERIES 16GB SFP+ SHORT WAVE TRANSCEIVER, 656435-001
Genuine HPE QK724A

Alternative Views:
Our Price: $30.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: QK724A
Qty:

Description

QK724A is the HPE B-series 16Gb SFP+SW XCVR. The HPE B-Series SFP+ Short Wave Transceiver is designed for B-series switches, including HPE SN8000B 32 and SN8000B 48. This high-performance SFP+ transceiver module is compatible with select HP personal computers. It comes with a short wave LC connector with 16 Gb fibre channel for an optimum performance. You need one SFP+ slot to connect this plug-in module.

Specifications
  • Model: QK724A
  • Form Factor: SFP+
  • Max Data Rate: 16Gbps
  • Wavelength: 850nm
  • Max Cable Distance: 100m @ OM3 MMF
  • Connector: LC duplex
  • Optical Components: VCSEL 850nm
  • Media: MMF
  • DOM Support: Yes
  • TX Power: -7.8~-1.3dBm
  • Receiver Sensitivity: <0dBm
  • Commercial Temperature Range: 0 to 70°C (32 to 158°F)
  • Protocols: MSA Compliant
Compatibility
The HPE QK724A is supported on a wide range of HPE equipments:
  • HP SN8000B 8-Slot Pwr Pack+ Dir Switch
  • HP SN8000B 16Gb 48-port FC Blade
