Ericsson RDH10270/1 CPRI & 10GBASE-BX20-U SFP+ BIDI Transceiver Module SPBD-10G3B4K1RE1
RDH10270-1 - Genuine Ericsson RDH10270/1

Alternative Views:
Our Price: $80.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: RDH10270-1
Qty:

Description

The Ericsson RDH10270/1 SFP+ transceiver supports up to 20km over OS2 SMF via an LC simplex connector. This transceiver is compliant with SFF-8431 and IEEE 802.3ae standard. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data center, 10G Ethernet etc.

Specifications
  • Manufacturer: Ericsson
  • Part Number: RDH10270/1
  • MPN: SPBD-10G3B4K1RE1
  • Form Factor: SFP+
  • Max Data Rate: 10Gbps
  • Wavelength: 1270nm-TX/1330nm-RX
  • Max Cable Distance: 20km
  • Connector: LC simplex
  • Optical Components: DFB BiDi
  • Media: SMF
  • DOM Support: Yes
  • TX Power: -6~3dBm
  • Receiver Sensitivity: <-14.4dBm
  • Commercial Temperature Range: 0 to 70°C (32 to 158°F)
  • Protocols: SFP+ MSA Compliant, CPRI, eCPRI
