RDH10275-3 - Genuine Ericsson RDH10275/3

Home > OEM > Ericsson >

Ericsson RDH10275/3 25GBASE-LR I-Temp 10km 1310nm SFP28 Transceiver Module

RDH10275-3 - Genuine Ericsson RDH10275/3

Alternative Views:

Our Price: $85.00

Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days

Product Code: RDH10275-3

Qty:

Description

The Ericsson RDH10275/3 SFP28 transceiver provides 25GBase-LR throughput up to 10km over single mode fiber (SMF) using a wavelength of 1310nm via an LC duplex connector. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center, suitable for both outdoor and indoor deployments. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard.

Specifications

Form Factor: SFP28
Max Data Rate: 25.78Gbps
Wavelength: 1310nm
Max Cable Distance: 10km
Connector: LC duplex
Media: SMF
Transmitter Type: DFB 1310nm
Receiver Type: PIN
DDM/DOM: Supported
Industrial Temperature Range: -40 to 85°C (-40 to 185°F)
TX Power: -4.5~2dBm
Receiver Sensitivity: <-11.4dBm
Powerbudget: 6.9dB
Receiver Overload: 2dBm
Power Consumption: <1.2W
Extinction Ratio: 2.7dB
Modulation Format: NRZ
CDR: TX & RX Built-in CDR
Transmit and Dispersion Penalty: 5dB
FEC Function: Not support
Packaging Technology: TO-CAN Packaging
EMC (Electromagnetic Compatibility): Supported
Protocols: SFF-8472, SFF-8402, SFF-8432, SFF-8431, CEI-28G-VSR
Application: 25GBASE-LR, CPRI option 10 / eCPRI
